KTM 300 XC 20132013 KTM 300 XC specifications, pictures, reviews and rating |
| KTM's profilation of this bike |
| The 300 XC provides the 2-stroke afficianado exactly what they want; awesome 2-stroke power and the chassis to utlize every bit of it. KTM continues to innovate and develop 2-strokes including a new single diaphgram clutch and V-Force reed cage for even more performance. |
| General information | |
|---|---|
| Model | KTM 300 XC |
| Model year | 2013 |
| Category | Enduro / offroad |
| Rating | 3.5 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
| Engine and transmission | |
| Displacement | 293.0 ccm (17.88 cubic inches) |
| Engine type | Single cylinder, two-stroke |
| Engine details | Reed intake. |
| Bore x stroke | 72.0 x 72.0 mm (2.8 x 2.8 inches) |
| Fuel system | Injection |
| Ignition | Contactless controlled fully electronic ignition with digital ignition adjustment, type Kokusan |
| Lubrication system | Forced oil lubrication with 2 Eaton pumps |
| Cooling system | Liquid |
| Gearbox | 6-speed |
| Clutch | Multidisc clutch in oil bath/hydraulically activated |
| Driveline | 14:50 |
| Chassis, suspension, brakes and wheels | |
| Frame type | Central tube frame made of chrome molybdenum steel tubing |
| Rake (fork angle) | 26.5° |
| Front suspension | WP Suspension Up Side Down 4860 MXMA CC |
| Front wheel travel | 292 mm (11.5 inches) |
| Rear suspension | WP Suspension 5018 BAVP DCC |
| Rear wheel travel | 335 mm (13.2 inches) |
| Front brakes | Single disc |
| Diameter | 260 mm (10.2 inches) |
| Rear brakes | Single disc |
| Diameter | 220 mm (8.7 inches) |
| Physical measures and capacities | |
| Dry weight | 104.0 kg (229.3 pounds) |
| Seat height | 992 mm (39.1 inches) If adjustable, lowest setting. |
| Ground clearance | 385 mm (15.2 inches) |
| Wheelbase | 1495 mm (58.9 inches) |
| Fuel capacity | 10.00 litres (2.64 US gallons) |
| Other specifications | |
| Color options | Orange/gray |
| Starter | Electric & kick |
| Update specs | Report missing specs or required updates. |
| Further information | |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Parts finder | Check out our overview of motorcycle webshops at Bikez.info. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 13 KTM 300 XC discussion group or the general KTM discussion group. |
| Related bikes | List related bikes for comparison of specs. |
| Compare with another motorcycle | |
Rate motorcycles you know
Rate motorcycles you know and help your fellow riders to find the bike that is right for them. Bikez has the most users and the most extensive motorcycle rating on the net. It includes reliability, design, engine performance, accident risk, repair cost, offroad capabilities, racing track capabilities and touring capabilities. The ratings are also used to rank the 100 most popular MC models each year since 1990. The lists are adjusted weekly as new ratings are added. You can check out the rating of the 2013 KTM 300 XC and compare it to other bikes here.| Rating sample for this KTM bike | |
Reliability for the 2013 KTM 300 XC:  (69.3 out of 100)Click here for complete rating. |
|
