KTM 250 EXC Racing 20052005 KTM 250 EXC Racing specifications, pictures, reviews and rating |
| KTM's profilation of this bike |
| The 250 EXC Racing is an agile bike that urges gently down below and inspires with predictable power up top. The precise handling and the nicely controllable riding behaviour spare stamina and ensure maximum fun factor. |
| General information | |
|---|---|
| Model | KTM 250 EXC Racing |
| Model year | 2005 |
| Category | Cross / motocross |
| Rating | 3.3 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
| Engine and transmission | |
| Displacement | 249.6 ccm (15.23 cubic inches) |
| Engine type | Single cylinder, four-stroke |
| Compression | 12.0:1 |
| Bore x stroke | 75.0 x 56.6 mm (3.0 x 2.2 inches) |
| Valves per cylinder | 4 |
| Fuel system | Carburettor. Keihin MX FCR 37 |
| Fuel control | Overhead Cams (OHC) |
| Ignition | Kokusan digital 4K-3B |
| Lubrication system | Pressure lubrication with 2 Eaton pumps |
| Cooling system | Liquid |
| Gearbox | 6-speed |
| Transmission type | Chain (final drive) |
| Clutch | Wet multi-disc clutch, operated hydraulically |
| Chassis, suspension, brakes and wheels | |
| Frame type | Chromium molybdenum |
| Rake (fork angle) | 26.5° |
| Trail | 112 mm (4.4 inches) |
| Front suspension | WP-USD 48 mm |
| Rear suspension | WP-PDS-shock absorber |
| Rear wheel travel | 335 mm (13.2 inches) |
| Front brakes | Single disc |
| Diameter | 216 mm (8.5 inches) |
| Rear brakes | Single disc |
| Diameter | 260 mm (10.2 inches) |
| Physical measures and capacities | |
| Dry weight | 113.7 kg (250.7 pounds) |
| Seat height | 925 mm (36.4 inches) If adjustable, lowest setting. |
| Ground clearance | 380 mm (15.0 inches) |
| Wheelbase | 1481 mm (58.3 inches) |
| Fuel capacity | 8.00 litres (2.11 US gallons) |
| Other specifications | |
| Starter | Electric & kick |
| Update specs | Report missing specs or required updates. |
| Further information | |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Parts finder | Check out our overview of motorcycle webshops at Bikez.info. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 05 KTM 250 EXC Racing discussion group or the general KTM discussion group. |
| Related bikes | List related bikes for comparison of specs. |
