| KTM's profilation of this bike |
| Performance approaching that of a 250 with the handling of a 125. The perfect all-rounder in the 2-stroke segment appears even more aggressive now with new bodywork and significantly revamped suspension. You can´t go wrong here. |
|
General information |
|
Model name
|
KTM 150 SX |
|
Model year
|
2013 |
|
Category
|
Cross / motocross |
|
Rating
|
3.7 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
143.6 ccm (8.76 cubic inches) |
|
Engine type
|
Single cylinder, two-stroke |
|
Engine details
|
Reed intake. |
|
Bore x stroke
|
56.0 x 58.4 mm (2.2 x 2.3 inches) |
|
Ignition
|
Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment, type Kokusan |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Wet multi-disc clutch / hydraulically operated |
|
Driveline
|
14:50. Primary drive: 23:73. |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Central tube frame made of chrome molybdenum steel tubing |
|
Rake (fork angle)
|
26.5° |
|
Front suspension
|
WP Suspension Up Side Down 4860 MXMA CC |
|
Front wheel travel
|
205 mm (8.1 inches) |
|
Rear suspension
|
WP Suspension 5018 BAVP DCC |
|
Rear wheel travel
|
185 mm (7.3 inches) |
|
Front brakes
|
Single disc. Four-piston calipers. |
|
Diameter
|
220 mm (8.7 inches) |
|
Rear brakes
|
Single disc. Two-piston calipers. |
|
Diameter
|
210 mm (8.3 inches) |
|
Physical measures and capacities |
|
Dry weight
|
90.8 kg (200.2 pounds) |
|
Seat height
|
992 mm (39.1 inches) If adjustable, lowest setting. |
|
Ground clearance
|
395 mm (15.6 inches) |
|
Wheelbase
|
1480 mm (58.3 inches) |
|
Fuel capacity
|
7.50 litres (1.98 US gallons) |
|
Other specifications |
|
Color options
|
Orange/black |
|
Starter
|
Kick |
