| KTM's profilation of this bike |
| What is small, ferocious and delivers enough power to show the competition your rear wheel? The powerhouse from KTM has been an absolute norm for years when it comes to power output, engine speed consistency and reliabilit |
|
General information |
|
Model name
|
KTM 144 SX |
|
Year
|
2008 |
|
Category
|
Enduro / offroad |
|
Rating
|
3.6 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
143.6 ccm (8.76 cubic inches) |
|
Engine type
|
Single cylinder, two-stroke |
|
Bore x stroke
|
56.0 x 58.5 mm (2.2 x 2.3 inches) |
|
Fuel system
|
Carburettor. Keihin PWK 39 |
|
Ignition
|
Kokusan digital Magnet CDI |
|
Lubrication system
|
Mixture oil lubrication 1:40 |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Clutch
|
Wet multi-disc clutch, operated hydraulically |
|
Exhaust system
|
Aluminium |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Cental double-cradle-type 25 CrMo4 |
|
Rake (fork angle)
|
27.0° |
|
Front suspension
|
WP USD 48 mm |
|
Front wheel travel
|
300 mm (11.8 inches) |
|
Rear suspension
|
WP Monoshock PDS |
|
Rear wheel travel
|
335 mm (13.2 inches) |
|
Front tire
|
80/100-21 |
|
Rear tire
|
100/90-19 |
|
Front brakes
|
Single disc |
|
Rear brakes
|
Single disc |
|
Physical measures and capacities |
|
Dry weight
|
90.8 kg (200.2 pounds) |
|
Seat height
|
925 mm (36.4 inches) If adjustable, lowest setting. |
|
Ground clearance
|
390 mm (15.4 inches) |
|
Wheelbase
|
1471 mm (57.9 inches) |
|
Fuel capacity
|
7.50 litres (1.98 US gallons) |
|
Other specifications |
|
Starter
|
Kick |
