| KTM's profilation of this bike |
| The advantage of the feather-light 125 EXC is right there where the terrain is so tough it even stops the mountain goats. As light as a trial bike, this one can circle around any nasty tricks nature can come up with. And with the new cylinder, this small two-stroke has never been stronger.
|
| General information |
|---|
| Model | KTM 125 EXC |
| Year | 2007 |
| Category | Enduro / offroad |
| Rating | 3.7 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
| Engine and transmission |
|---|
| Displacement | 124.8 ccm (7.62 cubic inches) |
| Engine type | Single cylinder, two-stroke |
| Compression | 12.5:1 |
| Bore x stroke | 54.0 x 54.5 mm (2.1 x 2.1 inches) |
| Fuel system | Carburettor. Keihin PWK 36 S AG |
| Ignition | Kokusan digital 2K-3 |
| Lubrication system | Mixture oil lubrication 1:40 |
| Cooling system | Liquid |
| Gearbox | 6-speed |
| Clutch | Wet multi-disc clutch, operated hydraulically |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type | Central double-cradle-type 25CrMo4 |
| Rake (fork angle) | 27.0° |
| Front suspension | WP USD |
| Front wheel travel | 115 mm (4.5 inches) |
| Rear suspension | WP monoshock PDS |
| Rear wheel travel | 185 mm (7.3 inches) |
| Front tire | 90/90-21 |
| Rear tire | 120/90-18 |
| Front brakes | Single disc |
| Rear brakes | Single disc |
| Physical measures and capacities |
|---|
| Dry weight | 98.6 kg (217.4 pounds) |
| Seat height | 925 mm (36.4 inches) If adjustable, lowest setting. |
| Ground clearance | 390 mm (15.4 inches) |
| Wheelbase | 1471 mm (57.9 inches) |
| Fuel capacity | 8.50 litres (2.25 US gallons) |
| Other specifications |
|---|
| Starter | Kick |
