| KTM's profilation of this bike |
| The 125 ESC demonstrates its phenomenal power-to-weight ratio above all in the toughest terrain. Light as a trials bike, it simply floats over rock steps and other nasties. The refined chassis, together with a broad, usable rev band for a small 2-stroke, provide huge amounts of riding fun.
|
| General information |
|---|
| Model | KTM 125 EXC |
| Year | 2005 |
| Category | Cross / motocross |
| Rating | 3.0 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
| Engine and transmission |
|---|
| Displacement | 124.8 ccm (7.62 cubic inches) |
| Engine type | Single cylinder, two-stroke |
| Compression | 11.0:1 |
| Bore x stroke | 54.0 x 54.5 mm (2.1 x 2.1 inches) |
| Fuel system | Carburettor. Keihin PWK 38 AG |
| Ignition | Kokusan digital 2K-3 |
| Lubrication system | mixture oil lubrication 1:40 |
| Cooling system | Liquid |
| Gearbox | 6-speed |
| Transmission type | Chain (final drive) |
| Clutch | wet multi-disc clutch, operated hydraulically |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type | chromium molybdenum |
| Rake (fork angle) | 27.0° |
| Trail | 116 mm (4.6 inches) |
| Front suspension | WP-USD 48 mm (1.89ยด |
| Rear suspension | WP-PDS-shock absorber |
| Rear wheel travel | 335 mm (13.2 inches) |
| Front brakes | Single disc |
| Diameter | 216 mm (8.5 inches) |
| Rear brakes | Single disc |
| Diameter | 260 mm (10.2 inches) |
| Physical measures and capacities |
|---|
| Dry weight | 98.6 kg (217.4 pounds) |
| Seat height | 925 mm (36.4 inches) If adjustable, lowest setting. |
| Ground clearance | 390 mm (15.4 inches) |
| Wheelbase | 1471 mm (57.9 inches) |
| Fuel capacity | 8.50 litres (2.25 US gallons) |
| Other specifications |
|---|
| Starter | Kick |
| Comments | Not available in the USA. |
| Update specs | Report missing specs or required updates. |
| Further information |
|---|
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Parts finder |
Check out our overview of motorcycle webshops at Bikez.info. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 05 KTM 125 EXC discussion group or the general KTM discussion group. |
| Related bikes | List related bikes for comparison of specs. |
|
|
|
Rating sample for this KTM bike
|
Touring capabilities for the 2005 KTM 125 EXC:
 (40.3 out of 100)
Click here for complete rating. You can also compare bikes.
|
|
