| Keeway's profilation of this bike |
| This small scooter is a blend of classical and modern design. It features a fully automatic 50cc 2-stroke engine coupled with 10 inch rims that are the perfect combination for zipping through urban areas. |
|
General moped information |
|
Model name
|
Keeway Pixel 50 |
|
Year of manufacture
|
2009 |
|
Type
|
Scooter |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. |
|
Engine and transmission |
|
Engine size
|
49.3 ccm (3.01 cubic inches) |
|
Type of engine
|
Single cylinder, two-stroke |
|
Output
|
3.3 HP (2.4 kW)) @ 5700 RPM |
|
Torque
|
4.3 Nm (0.4 kgf-m or 3.1 ft.lbs) @ 5500 RPM |
|
Top speed
|
45.0 km/h (28.0 mph) |
|
Compression
|
6.9:1 |
|
Bore x stroke
|
40.0 x 39.5 mm (1.6 x 1.6 inches) |
|
Ignition
|
C.D.I. |
|
Cooling system
|
Air |
|
Gearbox
|
Automatic |
|
Transmission type
|
Belt (final drive) |
|
Clutch
|
Wet shoe, multiplate |
|
Fuel consumption
|
2.40 litres/100 km (41.7 km/l or 98.01 mpg) |
|
Greenhouse gases
|
55.7 CO2 g/km. (CO2 - Carbon dioxide emission) |
|
Chassis, suspension, brakes and wheels |
|
Front tire
|
3.50-10 |
|
Rear tire
|
3.50-10 |
|
Front brakes
|
Single disc |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Physical measures and capacities |
|
Dry weight
|
88.0 kg (194.0 pounds) |
|
Power/weight ratio
|
0.0376 HP/kg |
|
Overall length
|
1775 mm (69.9 inches) |
|
Overall width
|
700 mm (27.6 inches) |
|
Ground clearance
|
180 mm (7.1 inches) |
|
Wheelbase
|
1170 mm (46.1 inches) |
|
Other specifications |
|
Starter
|
Electric & kick |
