| Keeway's profilation of this bike |
| A strong chassis and smoother suspension offer great stability and comfort. Braking is enforced through powerful front drums and a strong rear disk. |
|
General information |
|
Model name
|
Keeway ATV 100 |
|
Year model
|
2009 |
|
Type
|
ATV |
|
Rating
|
2.2 Check out the detailed rating of reliability, maintenance costs, value for money, etc. Compare with any other motorcycle. |
|
Engine and transmission |
|
Engine size
|
91.3 ccm (5.57 cubic inches) |
|
Type of engine
|
Single cylinder, two-stroke |
|
Effect
|
8.3 HP (6.1 kW)) @ 7500 RPM |
|
Torque
|
8.2 Nm (0.8 kgf-m or 6.0 ft.lbs) @ 7500 RPM |
|
Top speed
|
50.0 km/h (31.1 mph) |
|
Compression
|
6.4:1 |
|
Bore x stroke
|
52.0 x 43.0 mm (2.0 x 1.7 inches) |
|
Fuel system
|
Carburettor |
|
Cooling system
|
Air |
|
Gearbox
|
Automatic |
|
Transmission type
|
Belt (final drive) |
|
Fuel consumption
|
2.70 litres/100 km (37.0 km/l or 87.12 mpg) |
|
Greenhouse gases
|
62.6 CO2 g/km. (CO2 - Carbon dioxide emission) |
|
Chassis, suspension, brakes and wheels |
|
Front tire
|
19/7-8 |
|
Rear tire
|
18/10-10 |
|
Front brakes
|
Expanding brake (drum brake) |
|
Rear brakes
|
Single disc |
|
Physical measures and capacities |
|
Dry weight
|
125.0 kg (275.6 pounds) |
|
Power/weight ratio
|
0.0665 HP/kg |
|
Overall height
|
1010 mm (39.8 inches) |
|
Overall length
|
1403 mm (55.2 inches) |
|
Overall width
|
835 mm (32.9 inches) |
|
Ground clearance
|
135 mm (5.3 inches) |
|
Wheelbase
|
934 mm (36.8 inches) |
|
Fuel capacity
|
4.50 litres (1.19 US gallons) |
|
Other specifications |
|
Starter
|
Electric & kick |
