| Keeway's profilation of this bike |
| ARN offers superb versatility with smart, sporty aesthetics. |
|
General moped information |
|
Motorcycle name
|
Keeway ARN 50 |
|
Year of manufacture
|
2010 |
|
Type
|
Scooter |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
49.0 ccm (2.99 cubic inches) |
|
Type of engine
|
Single cylinder, two-stroke |
|
Output
|
3.9 HP (2.8 kW)) @ 6250 RPM |
|
Torque
|
4.2 Nm (0.4 kgf-m or 3.1 ft.lbs) @ 6000 RPM |
|
Compression
|
6.9:1 |
|
Fuel system
|
Carburettor |
|
Ignition
|
C.D.I. |
|
Transmission type
|
Belt (final drive) |
|
Clutch
|
Dry, centrifugal |
|
Fuel consumption
|
2.00 litres/100 km (50.0 km/l or 117.61 mpg) |
|
Greenhouse gases
|
46.4 CO2 g/km. (CO2 - Carbon dioxide emission) |
|
Chassis, suspension, brakes and wheels |
|
Front tire
|
120/70-12 |
|
Rear tire
|
130/70-12 |
|
Front brakes
|
Single disc |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Physical measures and capacities |
|
Dry weight
|
104.0 kg (229.3 pounds) |
|
Weight incl. oil, gas, etc
|
110.0 kg (242.5 pounds) |
|
Power/weight ratio
|
0.0374 HP/kg |
|
Overall height
|
1140 mm (44.9 inches) |
|
Overall length
|
1900 mm (74.8 inches) |
|
Overall width
|
700 mm (27.6 inches) |
|
Wheelbase
|
1300 mm (51.2 inches) |
|
Fuel capacity
|
6.00 litres (1.59 US gallons) |
|
Other specifications |
|
Color options
|
Blue, black, white |
|
Starter
|
Electric & kick |
