General information |
Model
|
Kawasaki ZN 700 LTD Shaft |
Year of manufacture
|
1984 |
Type
|
Classic |
Rating
|
3.6 See the detailed rating of design and look, engine performance, reliability, fun-factor, etc. Compare with any other bike. |
Engine and transmission |
Engine size
|
694.0 ccm (42.35 cubic inches) |
Type of engine
|
In-line four, four-stroke |
Output
|
74.0 HP (54.0 kW)) @ 9500 RPM |
Maximum RPM
|
10000 |
Compression
|
9.7:1 |
Bore x stroke
|
64.0 x 54.0 mm (2.5 x 2.1 inches) |
Valves per cylinder
|
2 |
Fuel system
|
Carburettor. Keihin CV34 x 4 |
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
Ignition
|
CDI |
Lubrication system
|
wet sump |
Cooling system
|
Air |
Gearbox
|
5-speed |
Transmission type
|
Shaft drive (cardan) (final drive) |
Clutch
|
wet plate |
Exhaust system
|
Dual stainless megaphone pipes |
Chassis, suspension, brakes and wheels |
Frame type
|
tubular, double cradle |
Rake (fork angle)
|
29.8° |
Trail
|
112 mm (4.4 inches) |
Front suspension
|
Telescopic fork |
Front wheel travel
|
160 mm (6.3 inches) |
Rear suspension
|
Swing arm with Dual air adjustable shocks |
Rear wheel travel
|
100 mm (3.9 inches) |
Front tire
|
110/90-18 61H |
Rear tire
|
130/90-16 67H |
Front brakes
|
Double disc. single piston calipers |
Rear brakes
|
Single disc |
Physical measures and capacities |
Dry weight
|
217.0 kg (478.4 pounds) |
Power/weight ratio
|
0.3410 HP/kg |
Seat height
|
755 mm (29.7 inches) If adjustable, lowest setting. |
Overall height
|
1210 mm (47.6 inches) |
Overall length
|
2220 mm (87.4 inches) |
Overall width
|
820 mm (32.3 inches) |
Ground clearance
|
150 mm (5.9 inches) |
Wheelbase
|
1510 mm (59.4 inches) |
Fuel capacity
|
13.90 litres (3.67 US gallons) |
Other specifications |
Color options
|
red metallic |
Starter
|
Electric |
