General information |
|
Model name
|
Kawasaki Vulcan 500 LTD |
|
Model year
|
2009 |
|
Category
|
Custom / cruiser |
| Price as new | US$ 5499. MSRP depends on country, taxes, accessories, etc. |
|
Rating
|
3.5 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
498.0 ccm (30.39 cubic inches) |
|
Engine type
|
Twin, four-stroke |
|
Compression
|
10.2:1 |
|
Bore x stroke
|
74.0 x 58.0 mm (2.9 x 2.3 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Carburettor. Keihin CVK32 x 2 |
|
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
|
Ignition
|
Digital TCBI |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Double-cradle, steel |
|
Rake (fork angle)
|
33.0° |
|
Trail
|
150 mm (5.9 inches) |
|
Front suspension
|
41mm hydraulic fork / 5.9 in. |
|
Rear suspension
|
Dual hydraulic shocks with five-way adjustable spring preload / 3.9 in. |
|
Front tire
|
100/90-19 |
|
Rear tire
|
140/90-15 |
|
Front brakes
|
Single disc |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Physical measures and capacities |
|
Dry weight
|
214.1 kg (471.9 pounds) |
|
Seat height
|
714 mm (28.1 inches) If adjustable, lowest setting. |
|
Overall height
|
1125 mm (44.3 inches) |
|
Overall length
|
2319 mm (91.3 inches) |
|
Overall width
|
831 mm (32.7 inches) |
|
Ground clearance
|
119 mm (4.7 inches) |
|
Wheelbase
|
1595 mm (62.8 inches) |
|
Fuel capacity
|
15.14 litres (4.00 US gallons) |
|
Other specifications |
|
Color options
|
Metallic Imperial Red |
|
Starter
|
Electric |
