General information |
|
Motorcycle name
|
Kawasaki VN Vulcan 1600 Classic Tourer |
|
Model year
|
2006 |
|
Category
|
Cross / motocross |
|
Rating
|
3.0 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
1552.0 ccm (94.70 cubic inches) |
|
Engine type
|
V2, four-stroke |
|
Power output
|
67.0 HP (48.9 kW)) @ 4700 RPM |
|
Torque
|
127.0 Nm (12.9 kgf-m or 93.7 ft.lbs) @ 2700 RPM |
|
Top speed
|
177.0 km/h (110.0 mph) |
|
Compression
|
9.0:1 |
|
Bore x stroke
|
102.0 x 95.0 mm (4.0 x 3.7 inches) |
|
Fuel system
|
Injection. DFI, 2x 36 mm |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Ignition
|
Digital |
|
Cooling system
|
Liquid |
|
Gearbox
|
5-speed |
|
Transmission type
|
Shaft drive (cardan) (final drive) |
|
Clutch
|
Wet, multi-plate, hydraulic operated |
|
Fuel consumption
|
6.08 litres/100 km (16.4 km/l or 38.69 mpg) |
|
Greenhouse gases
|
141.1 CO2 g/km. (CO2 - Carbon dioxide emission) |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Double-cradle, high-tensile steel |
|
Rake (fork angle)
|
32.0° |
|
Trail
|
184 mm (7.2 inches) |
|
Front suspension
|
Telescopic fork 41 mm |
|
Front wheel travel
|
150 mm (5.9 inches) |
|
Rear suspension
|
Swingarm with twin-shock |
|
Rear wheel travel
|
99 mm (3.9 inches) |
|
Front tire
|
150/80-M16 |
|
Rear tire
|
170/70-B16 |
|
Front brakes
|
Double disc. 2-piston calipers |
|
Diameter
|
300 mm (11.8 inches) |
|
Rear brakes
|
Single disc. 2-piston caliper |
|
Diameter
|
300 mm (11.8 inches) |
|
Physical measures and capacities |
|
Dry weight
|
350.0 kg (771.6 pounds) |
|
Weight incl. oil, gas, etc
|
377.0 kg (831.1 pounds) |
|
Power/weight ratio
|
0.1914 HP/kg |
|
Seat height
|
680 mm (26.8 inches) If adjustable, lowest setting. |
|
Overall height
|
1265 mm (49.8 inches) |
|
Overall length
|
2165 mm (85.2 inches) |
|
Overall width
|
815 mm (32.1 inches) |
|
Wheelbase
|
1685 mm (66.3 inches) |
|
Fuel capacity
|
20.00 litres (5.28 US gallons) |
|
Oil capacity
|
3.10 litres (3.28 US quarts) |
|
Other specifications |
|
Starter
|
Electric |
|
Electrical
|
12V-18Ah battery |
| Update specs | Report missing specs or required updates. |
|
Maintenance and service specs * |
|
Engine oil
|
SAE 10W-40 |
|
Brake fluid
|
DOT 4 |
|
Coolant
|
2.00 litres (0.53 US gallons) |
|
Spark plugs
|
NGK DPR6EA-9, - |
|
Idle speed
|
950 +/- 50 RPM |
|
Tire pressure front
|
29 PSI (2 Bar or 200 kPa) |
|
Tire pressure rear
|
36 PSI (2.5 Bar or 250 kPa) |
|
Fork tube size
|
43 mm (1.7 inches) |
| *) Always verify maintenance and service data with the bike owner's manual. |
|
