General information |
|
Model name
|
Kawasaki KX110 |
|
Year model
|
2013 |
|
Type
|
ATV |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
112.0 ccm (6.83 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Engine details
|
Reed valve. |
|
Effect
|
7.2 HP (5.3 kW)) @ 7500 RPM |
|
Torque
|
8.0 Nm (0.8 kgf-m or 5.9 ft.lbs) |
|
Compression
|
9.5:1 |
|
Bore x stroke
|
53.0 x 50.6 mm (2.1 x 2.0 inches) |
|
Fuel system
|
Carburettor |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Ignition
|
Digital DC-CDI |
|
Lubrication system
|
Forced lubrication, wet sump |
|
Cooling system
|
Air |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Centrifugal, wet multi-disc |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Steel backbone |
|
Front suspension
|
30 mm telescopic fork |
|
Rear suspension
|
Single shock |
|
Front tire
|
2.50-14 |
|
Rear tire
|
3.00-12 |
|
Front brakes
|
Expanding brake (drum brake) |
|
Diameter
|
248 mm (9.8 inches) |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Diameter
|
248 mm (9.8 inches) |
|
Physical measures and capacities |
|
Weight incl. oil, gas, etc
|
76.0 kg (167.6 pounds) |
|
Seat height
|
680 mm (26.8 inches) If adjustable, lowest setting. |
|
Overall height
|
955 mm (37.6 inches) |
|
Overall length
|
1560 mm (61.4 inches) |
|
Overall width
|
650 mm (25.6 inches) |
|
Ground clearance
|
215 mm (8.5 inches) |
|
Wheelbase
|
1075 mm (42.3 inches) |
|
Fuel capacity
|
3.80 litres (1.00 US gallons) |
|
Other specifications |
|
Starter
|
Electric & kick |
