Kawasaki KX110 20132013 Kawasaki KX110 specifications, pictures, reviews and rating |
| Kawasaki's profilation of this bike |
| New electric starter offers hassle-free starting. KACR (Kawasaki Automatic Compression Release) (using the intake valve) provides easy starting for both the electric starter and kick starter. |
| General information | |
|---|---|
| Model name | Kawasaki KX110 |
| Year model | 2013 |
| Type | ATV |
| Rating |
Do you know this bike? Click here to rate it. We miss 2 votes to show the rating. |
| Engine and transmission | |
| Engine size | 112.0 ccm (6.83 cubic inches) |
| Type of engine | Single cylinder, four-stroke |
| Engine details | Reed valve. |
| Effect | 7.2 HP (5.3 kW)) @ 7500 RPM |
| Torque | 8.0 Nm (0.8 kgf-m or 5.9 ft.lbs) |
| Compression | 9.5:1 |
| Bore x stroke | 53.0 x 50.6 mm (2.1 x 2.0 inches) |
| Fuel system | Carburettor |
| Fuel control | Single Overhead Cams (SOHC) |
| Ignition | Digital DC-CDI |
| Lubrication system | Forced lubrication, wet sump |
| Cooling system | Air |
| Transmission type | Chain (final drive) |
| Clutch | Centrifugal, wet multi-disc |
| Chassis, suspension, brakes and wheels | |
| Frame type | Steel backbone |
| Front suspension | 30 mm telescopic fork |
| Rear suspension | Single shock |
| Front tire | 2.50-14 |
| Rear tire | 3.00-12 |
| Front brakes | Expanding brake (drum brake) |
| Diameter | 248 mm (9.8 inches) |
| Rear brakes | Expanding brake (drum brake) |
| Diameter | 248 mm (9.8 inches) |
| Physical measures and capacities | |
| Weight incl. oil, gas, etc | 76.0 kg (167.6 pounds) |
| Seat height | 680 mm (26.8 inches) If adjustable, lowest setting. |
| Overall height | 955 mm (37.6 inches) |
| Overall length | 1560 mm (61.4 inches) |
| Overall width | 650 mm (25.6 inches) |
| Ground clearance | 215 mm (8.5 inches) |
| Wheelbase | 1075 mm (42.3 inches) |
| Fuel capacity | 3.80 litres (1.00 US gallons) |
| Other specifications | |
| Starter | Electric & kick |
| Update specs | Report missing specs or required updates. |
