General information |
|
Model name
|
Kawasaki KVF650 4x4 |
|
Year of manufacture
|
2013 |
|
Type
|
ATV |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
633.0 ccm (38.63 cubic inches) |
|
Type of engine
|
V2, four-stroke |
|
Output
|
46.5 HP (34.0 kW)) @ 7500 RPM |
|
Torque
|
51.4 Nm (5.2 kgf-m or 37.9 ft.lbs) @ 5250 RPM |
|
Compression
|
9.9:1 |
|
Bore x stroke
|
80.0 x 63.0 mm (3.1 x 2.5 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Carburettor. Keihin CVKR-34, 2 carburetors |
|
Ignition
|
Digital DC-CDI |
|
Cooling system
|
Liquid |
|
Transmission type
|
Shaft drive (cardan) (final drive) |
|
Driveline
|
2WD/4WD, shaft |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Double tubular |
|
Front suspension
|
MacPherson strut |
|
Rear suspension
|
Brakes |
|
Front tire
|
25/8-12 |
|
Rear tire
|
25/10-12 |
|
Front brakes
|
Double disc. Discs with twin piston calipers |
|
Diameter
|
200 mm (7.9 inches) |
|
Rear brakes
|
Sealed multidisc |
|
Physical measures and capacities |
|
Weight incl. oil, gas, etc
|
298.0 kg (657.0 pounds) |
|
Overall height
|
1235 mm (48.6 inches) |
|
Overall length
|
2195 mm (86.4 inches) |
|
Overall width
|
1165 mm (45.9 inches) |
|
Ground clearance
|
245 mm (9.6 inches) |
|
Wheelbase
|
1285 mm (50.6 inches) |
|
Fuel capacity
|
20.50 litres (5.42 US gallons) |
|
Other specifications |
|
Color options
|
Black |
|
Starter
|
Electric |
|
Electrical
|
Starting battery. |
|
Carrying capacity
|
Front and rear rack |
