Kawasaki's profilation of this bike |
Powered by a torquey and responsive air-cooled 125cc four-stroke single, the KLX125L pumps out plenty of rider-friendly power for off-road fun. The engine is specially tuned for low and mid-range power, and a smooth shifting five-speed transmission means there´s a gear for every riding situation. |
General information |
Motorcycle name
|
Kawasaki KLX 125 L |
Year of manufacture
|
2005 |
Type
|
Enduro / offroad |
Price as new | US$ 2499. MSRP depends on country, taxes, accessories, etc. |
Rating
|
3.2 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
Engine and transmission |
Engine size
|
124.0 ccm (7.57 cubic inches) |
Type of engine
|
Single cylinder, two-stroke |
Compression
|
9.5:1 |
Bore x stroke
|
57.0 x 48.8 mm (2.2 x 1.9 inches) |
Valves per cylinder
|
2 |
Fuel system
|
Carburettor. Mikuni VM20SS |
Fuel control
|
Single Overhead Cams (SOHC) |
Ignition
|
Digital CDI |
Gearbox
|
5-speed |
Transmission type
|
Chain (final drive) |
Chassis, suspension, brakes and wheels |
Frame type
|
High-tensile, diamond tube steel |
Rake (fork angle)
|
26.5° |
Front suspension
|
Telescopic fork, 48mm |
Rear suspension
|
Bottom-link, single shock |
Front tire
|
70/90-19 |
Rear tire
|
90/80-16 |
Front brakes
|
Expanding brake (drum brake) |
Rear brakes
|
Expanding brake (drum brake) |
Physical measures and capacities |
Dry weight
|
81.0 kg (178.5 pounds) |
Seat height
|
805 mm (31.7 inches) If adjustable, lowest setting. |
Overall height
|
1095 mm (43.1 inches) |
Overall width
|
770 mm (30.3 inches) |
Ground clearance
|
290 mm (11.4 inches) |
Wheelbase
|
1270 mm (50.0 inches) |
Fuel capacity
|
6.43 litres (1.70 US gallons) |
Other specifications |
Color options
|
Kawasaki Lime Green |
