Johnny Pag Spyder 20102010 Johnny Pag Spyder specifications, pictures, reviews and rating |
| Johnny Pag's profilation of this bike |
| We offset the triple trees for better handling and less front end flop. |
| General information | |
|---|---|
| Model name | Johnny Pag Spyder |
| Model year | 2010 |
| Category | Custom / cruiser |
| Price as new | US$ 4699. MSRP depends on country, taxes, accessories, etc. |
| Rating | 3.2 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
| Engine and transmission | |
| Displacement | 300.0 ccm (18.31 cubic inches) |
| Engine type | Twin, four-stroke |
| Power output | 23.8 HP (17.4 kW)) @ 6500 RPM |
| Torque | 18.5 Nm (1.9 kgf-m or 13.6 ft.lbs) @ 6500 RPM |
| Bore x stroke | 57.0 x 53.0 mm (2.2 x 2.1 inches) |
| Valves per cylinder | 2 |
| Fuel system | Carburettor. Dual 26mm Keihin Vacuum Carburetor |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Ignition | C.D.I. |
| Lubrication system | Forced Lubrication |
| Cooling system | Liquid |
| Gearbox | 5-speed |
| Clutch | Multiplate oil bath |
| Fuel consumption | 3.61 litres/100 km (27.7 km/l or 65.16 mpg) |
| Greenhouse gases | 83.8 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Chassis, suspension, brakes and wheels | |
| Rake (fork angle) | 42.0° |
| Front suspension | 39 mm telescopic forks |
| Rear suspension | Dual shocks, fully-adjustable |
| Front tire | 80/90-21 |
| Rear tire | 160/90-18 |
| Front brakes | Double disc. 2 piston calipers |
| Rear brakes | Single disc. 2 piston calipers |
| Physical measures and capacities | |
| Weight incl. oil, gas, etc | 163.3 kg (360.0 pounds) |
| Seat height | 508 mm (20.0 inches) If adjustable, lowest setting. |
| Alternate seat height | 584 mm (23.0 inches) If adjustable, highest setting. |
| Ground clearance | 152 mm (6.0 inches) |
| Wheelbase | 1854 mm (73.0 inches) |
| Other specifications | |
| Color options | Solid Black, Black w/silver flames, Red w/silver flames, Blue w/silver flames, Silver w/silver flames |
| Comments | Also called JPM Spyder 300. Located in Orange County, California. |
| Update specs | Report missing specs or required updates. |
| Further information | |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Parts finder | Check out our overview of motorcycle webshops at Bikez.info. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 10 Johnny Pag Spyder discussion group or the general Johnny Pag discussion group. |
| Related bikes | List related bikes for comparison of specs. |
| Compare with another motorcycle | |
Discussions for every bike
Bikez has discussion forums for every bike. View comments, questions and answers at the 2010 Johnny Pag Spyder discussion group. You can sign up for e-mail notifications when other riders answer you. If you have extensive experience with the MC, please send us a review. If you consider buying this bike, you should view the list of related motorbikes Look at photos. Compare technical specs. And check out the rating of the bike's engine performance, reliability, repair costs, etc. You can compare the rating with other bikes.| Rating sample for this Johnny Pag bike | |
Touring capabilities for the 2010 Johnny Pag Spyder:  (33.5 out of 100)Click here for complete rating. |
|
