Jawa-CZ' profilation of this bike |
JAWA 50 Robby is the simple motorcycle convenient not only for beginners but also for people preferring small 4-stroke motorcycle for shorter distances. |
General moped information |
Model
|
Jawa-CZ 50 Robby |
Year model
|
2013 |
Type
|
Sport |
Rating
|
Do you know this bike? Click here to rate it. We miss 1 vote to show the rating. |
Engine and transmission |
Engine size
|
49.5 ccm (3.02 cubic inches) |
Type of engine
|
Single cylinder, four-stroke |
Effect
|
3.0 HP (2.2 kW)) @ 9250 RPM |
Torque
|
3.2 Nm (0.3 kgf-m or 2.4 ft.lbs) @ 5500 RPM |
Top speed
|
48.0 km/h (29.8 mph) |
Compression
|
8.5:1 |
Bore x stroke
|
39.0 x 41.4 mm (1.5 x 1.6 inches) |
Fuel system
|
Carburettor |
Fuel control
|
Single Overhead Cams (SOHC) |
Cooling system
|
Air |
Gearbox
|
4-speed |
Transmission type
|
Chain (final drive) |
Chassis, suspension, brakes and wheels |
Frame type
|
Steel |
Front suspension
|
Telescopic forks |
Front wheel travel
|
80 mm (3.1 inches) |
Rear suspension
|
Hydraulic telescopic |
Rear wheel travel
|
70 mm (2.8 inches) |
Front tire
|
2.50-16 |
Rear tire
|
3.00-16 |
Front brakes
|
Single disc |
Diameter
|
200 mm (7.9 inches) |
Rear brakes
|
Expanding brake (drum brake) |
Diameter
|
124 mm (4.9 inches) |
Wheels
|
Black, 3-spoke aluminium alloy |
Seat
|
2-person seat |
Physical measures and capacities |
Dry weight
|
87.0 kg (191.8 pounds) |
Weight incl. oil, gas, etc
|
94.0 kg (207.2 pounds) |
Power/weight ratio
|
0.0339 HP/kg |
Seat height
|
730 mm (28.7 inches) If adjustable, lowest setting. |
Overall width
|
730 mm (28.7 inches) |
Wheelbase
|
1200 mm (47.2 inches) |
Fuel capacity
|
6.50 litres (1.72 US gallons) |
Reserve fuel capacity
|
1.20 litres (0.32 US gallons) |
Other specifications |
Color options
|
Red/black/gray, yellow/white, green/white |
Starter
|
Electric & kick |
