| Jawa-CZ' profilation of this bike |
| JAWA 100 Robby – motorcycle extending the offer of „small motorcycles“, which is different from JAWA 50 Robby only by using more powerful 4 - stroke engine. |
|
General information |
|
Motorcycle name
|
Jawa-CZ 100 Robby |
|
Model year
|
2006 |
|
Category
|
Sport |
|
Rating
|
3.2 Check out the detailed rating of racing track capabilities, engine performance, accident risk, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
97.0 ccm (5.92 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Power output
|
6.4 HP (4.6 kW)) @ 7750 RPM |
|
Torque
|
6.5 Nm (0.7 kgf-m or 4.8 ft.lbs) @ 5500 RPM |
|
Top speed
|
80.0 km/h (49.7 mph) |
|
Compression
|
8.8:1 |
|
Bore x stroke
|
50.0 x 49.5 mm (2.0 x 1.9 inches) |
|
Cooling system
|
Air |
|
Gearbox
|
4-speed |
|
Transmission type
|
Chain (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Telescopic forks 80mm |
|
Rear suspension
|
Teleskopic units 70mm |
|
Front tire
|
2.00-16 |
|
Rear tire
|
2.25-16 |
|
Front brakes
|
Single disc |
|
Diameter
|
200 mm (7.9 inches) |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Diameter
|
124 mm (4.9 inches) |
|
Physical measures and capacities |
|
Dry weight
|
82.0 kg (180.8 pounds) |
|
Power/weight ratio
|
0.0776 HP/kg |
|
Seat height
|
800 mm (31.5 inches) If adjustable, lowest setting. |
|
Wheelbase
|
1200 mm (47.2 inches) |
|
Fuel capacity
|
24.60 litres (6.50 US gallons) |
|
Other specifications |
|
Starter
|
Kick |
