Honda XR650L 20132013 Honda XR650L specifications, pictures, reviews and rating |
| Honda's profilation of this bike |
| It all starts in the engine room, where the XR´s potent, 644cc OHC powerplant uses Honda´s patented Radial Four-Valve Combustion Chamber (RFVC) to put out huge torque and power. From there, a gear-driven counterbalancer minimizes vibrations, while a light, rigid chassis and long-travel suspension soak up the bumps and deliver superb handling on pavement and off. Handy electric starting simply makes it all that much easier. |
| General information | |
|---|---|
| Model | Honda XR650L |
| Model year | 2013 |
| Category | Enduro / offroad |
| Price as new | US$ 23990. MSRP depends on country, taxes, accessories, etc. |
| Rating | 3.3 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
| Engine and transmission | |
| Displacement | 644.0 ccm (39.30 cubic inches) |
| Engine type | Single cylinder, four-stroke |
| Compression | 8.3:1 |
| Bore x stroke | 100.0 x 82.0 mm (3.9 x 3.2 inches) |
| Fuel system | Carburettor. 42.5mm diaphragm-type CV carburetor |
| Fuel control | Single Overhead Cams (SOHC) |
| Ignition | Solid-state CD with electronic advance |
| Lubrication system | Dry sump |
| Cooling system | Air |
| Gearbox | 5-speed |
| Transmission type | Chain (final drive) |
| Driveline | #520 O-ring-sealed chain; 15T/45T |
| Fuel consumption | 4.52 litres/100 km (22.1 km/l or 52.04 mpg) |
| Greenhouse gases | 104.9 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Emission details | Meets current CARB and EPA standards. California version differs slightly due to emissions equipment. |
| Chassis, suspension, brakes and wheels | |
| Rake (fork angle) | 27.0° |
| Trail | 102 mm (4.0 inches) |
| Front suspension | 43mm air-adjustable leading-axle Showa cartridge fork with 16-position compression-damping adjustability |
| Front wheel travel | 295 mm (11.6 inches) |
| Rear suspension | Pro-link Showa® single-shock with spring-preload, 20-position compression- and 20-position rebound-damping adjustability |
| Rear wheel travel | 279 mm (11.0 inches) |
| Front tire | 3.00-21 |
| Rear tire | 4.60-18 |
| Front brakes | Double disc. Two-piston calipers. |
| Rear brakes | Single disc |
| Physical measures and capacities | |
| Weight incl. oil, gas, etc | 156.9 kg (346.0 pounds) |
| Seat height | 940 mm (37.0 inches) If adjustable, lowest setting. |
| Ground clearance | 330 mm (13.0 inches) |
| Wheelbase | 1455 mm (57.3 inches) |
| Fuel capacity | 10.60 litres (2.80 US gallons) |
| Other specifications | |
| Color options | Red |
| Factory warranty | One year. Unlimited milage. Transferable. |
| Comments | Model ID: XR650L |
