2005 Honda VTX 1300 R

Honda VTX 1300 R 2005


2005 Honda VTX 1300 R specifications, pictures, reviews and rating

Honda's profilation of this bike
The VTX1300R has everything you would expect in a retro motorcycle. Cast wheels. Dual exhaust with custom-looking short pipes. And crisp tank-mounted instruments and gauges.

General information
Model Honda VTX 1300 R
Year model 2005
Type Custom / cruiser
Price as newUS$ 9299. MSRP depends on country, taxes, accessories, etc.
Rating 4.0  See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike.
Engine and transmission
Engine size 1312.0 ccm (80.06 cubic inches)
Type of engine V2, four-stroke
Compression 9.2:1
Bore x stroke 89.5 x 104.3 mm (3.5 x 4.1 inches)
Valves per cylinder 3
Fuel system Carburettor. Single 38mm CV
Fuel control Single Overhead Cams (SOHC)
Ignition Digital with three-dimensional mapping, two spark plugs per cylinder
Cooling system Liquid
Gearbox 5-speed
Transmission type Shaft drive (cardan) (final drive)
Chassis, suspension, brakes and wheels
Frame type Aluminium
Rake (fork angle) 32.0°
Trail 144 mm (5.7 inches)
Front suspension 41mm fork
Front wheel travel 130 mm (5.1 inches)
Rear suspension Dual shocks with five-position spring-preload adjustability
Rear wheel travel 94 mm (3.7 inches)
Front tire 140/80-17
Rear tire 170/80-15
Front brakes Single disc. 2-piston calipers.
Diameter 336 mm (13.2 inches)
Rear brakes Single disc. 1-piston calipers.
Diameter 296 mm (11.7 inches)
Physical measures and capacities
Dry weight 303.5 kg (669.0 pounds)
Seat height 695 mm (27.4 inches) If adjustable, lowest setting.
Wheelbase 1669 mm (65.7 inches)
Fuel capacity 18.16 litres (4.80 US gallons)
Other specifications
Color options Black, Metallic Silver, Candy Red, Magenta Metallic
Starter Electric
Comments Model ID: VTX1300R
