Honda VTX1300R 20112011 Honda VTX1300R specifications, pictures, reviews and rating |
| Honda's profilation of this bike |
| Ever wanted to know what it would be like to turn back the clock? Well, here´s your chance, courtesy of Honda´s classic VTX1300C. Fire up the big 1312cc V-twin and soak in the throaty exhaust note playing from the two-into-two, bullet-style mufflers. |
| General information | |
|---|---|
| Model | Honda VTX1300R |
| Year | 2011 |
| Category | Custom / cruiser |
| Price as new | US$ 10199. MSRP depends on country, taxes, accessories, etc. |
| Rating | 3.6 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
| Engine and transmission | |
| Displacement | 1312.0 ccm (80.06 cubic inches) |
| Engine type | V2, four-stroke |
| Compression | 9.2:1 |
| Bore x stroke | 89.5 x 104.3 mm (3.5 x 4.1 inches) |
| Valves per cylinder | 3 |
| Fuel system | Carburettor. Single 38mm constant-velocity carburetor |
| Fuel control | Single Overhead Cams (SOHC) |
| Ignition | Digital with three-dimensional mapping, two spark plugs per cylinder |
| Cooling system | Liquid |
| Gearbox | 5-speed |
| Transmission type | Shaft drive (cardan) (final drive) |
| Emission details | Meets current EPA emissions standards. California version meets current California Air Resources Board (CARB) standards and may differ slightly due to emissions equipment |
| Chassis, suspension, brakes and wheels | |
| Rake (fork angle) | 32.0° |
| Trail | 144 mm (5.7 inches) |
| Front suspension | 41mm fork |
| Front wheel travel | 130 mm (5.1 inches) |
| Rear suspension | Rear: Dual shocks with five-position spring-preload adjustability |
| Rear wheel travel | 94 mm (3.7 inches) |
| Front tire | 140/80-17 |
| Rear tire | 170/80-15 |
| Front brakes | Double disc |
| Diameter | 336 mm (13.2 inches) |
| Rear brakes | Single disc |
| Diameter | 296 mm (11.7 inches) |
| Physical measures and capacities | |
| Weight incl. oil, gas, etc | 322.1 kg (710.0 pounds) |
| Seat height | 696 mm (27.4 inches) If adjustable, lowest setting. |
| Wheelbase | 1669 mm (65.7 inches) |
| Fuel capacity | 18.17 litres (4.80 US gallons) |
| Other specifications | |
| Color options | Metallic Silver, Metallic Black and Bright Blue Metallic |
| Factory warranty | 1 year. |
| Comments | Model ID: VTX1300R |
