Honda VT 750 C2 Shadow 20022002 Honda VT 750 C2 Shadow specifications, pictures, reviews and rating |
| General information | |
|---|---|
| Model | Honda VT 750 C2 Shadow |
| Year of manufacture | 2002 |
| Type | Custom / cruiser |
| Rating | 3.6 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
| Engine and transmission | |
| Engine size | 745.0 ccm (45.46 cubic inches) |
| Type of engine | V2, four-stroke |
| Output | 45.2 HP (33.0 kW)) @ 5500 RPM |
| Torque | 63.0 Nm (6.4 kgf-m or 46.5 ft.lbs) @ 3000 RPM |
| Compression | 9.0:1 |
| Bore x stroke | 79.0 x 76.0 mm (3.1 x 3.0 inches) |
| Valves per cylinder | 3 |
| Fuel system | Carburettor |
| Gearbox | 5-speed |
| Transmission type | Chain (final drive) |
| Chassis, suspension, brakes and wheels | |
| Front wheel travel | 116 mm (4.6 inches) |
| Rear wheel travel | 90 mm (3.5 inches) |
| Front tire | 120/90-17 64S |
| Rear tire | 170/80-15M/C 77S |
| Front brakes | Single disc |
| Diameter | 296 mm (11.7 inches) |
| Rear brakes | Expanding brake |
| Diameter | 180 mm (7.1 inches) |
| Physical measures and capacities | |
| Dry weight | 229.0 kg (504.9 pounds) |
| Power/weight ratio | 0.1974 HP/kg |
| Seat height | 700 mm (27.6 inches) If adjustable, lowest setting. |
| Overall height | 1110 mm (43.7 inches) |
| Overall length | 2455 mm (96.7 inches) |
| Overall width | 980 mm (38.6 inches) |
| Ground clearance | 145 mm (5.7 inches) |
| Wheelbase | 1615 mm (63.6 inches) |
| Fuel capacity | 14.00 litres (3.70 US gallons) |
| Reserve fuel capacity | 3.60 litres (0.95 US gallons) |
| Other specifications | |
| Update specs | Report missing specs or required updates. |
| Further information | |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Parts finder | CMSNL provides
online schematics & OEM parts |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 02 Honda VT 750 C2 Shadow discussion group or the general Honda discussion group. |
| Related bikes | List related bikes for comparison of specs. |
| Compare with another motorcycle | |
Buying a bike starts at Bikez
Get a list of related motorbikes before you buy this Honda. Inspect technical data. Look at photos. Read the riders' comments at the bike's discussion group. And check out the bike's reliability, repair costs, etc. Show any 2002 Honda VT 750 C2 Shadow for sale on our Bikez.biz Motorcycle Classifieds. You can also sign up for e-mail notification when such bikes are advertised in the future. And advertise your old MC for sale. Our efficient ads are free. You are also welcome to read and submit motorcycle reviews.| Rating sample for this Honda bike | |
Racing track capabilities for the 2002 Honda VT 750 C2 Shadow:  (34.6 out of 100)Click here for complete rating. |
|
