Honda V-Twin Magna 20062006 Honda V-Twin Magna specifications, pictures, reviews and rating |
 2006 Honda V-Twin Magna. Picture credits - Honda. Submit more pictures. |
|
| General information | |
|---|---|
| Model name | Honda V-Twin Magna |
| Year model | 2006 |
| Type | Custom / cruiser |
| Rating | 3.5 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
| Engine and transmission | |
| Engine size | 229.0 ccm (13.97 cubic inches) |
| Type of engine | V2, four-stroke |
| Effect | 26.8 HP (19.6 kW)) @ 10000 RPM |
| Torque | 23.0 Nm (2.3 kgf-m or 17.0 ft.lbs) @ 7500 RPM |
| Compression | 11.0:1 |
| Bore x stroke | 60.0 x 44.1 mm (2.4 x 1.7 inches) |
| Valves per cylinder | 2 |
| Fuel system | Carburettor |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Cooling system | Liquid |
| Gearbox | 5-speed |
| Transmission type | Chain (final drive) |
| Clutch | Wet multiple plate coil springs |
| Chassis, suspension, brakes and wheels | |
| Frame type | Double cradle, steel |
| Front suspension | Cartridge fork |
| Rear suspension | Mono shock, swingarm |
| Front tire | 120/80-17 |
| Rear tire | 150/80-15 |
| Front brakes | Single disc |
| Rear brakes | Expanding brake (drum brake) |
| Physical measures and capacities | |
| Dry weight | 172.0 kg (379.2 pounds) |
| Weight incl. oil, gas, etc | 184.0 kg (405.7 pounds) |
| Power/weight ratio | 0.1559 HP/kg |
| Seat height | 755 mm (29.7 inches) If adjustable, lowest setting. |
| Overall height | 1155 mm (45.5 inches) |
| Overall length | 2315 mm (91.1 inches) |
| Wheelbase | 1620 mm (63.8 inches) |
| Fuel capacity | 11.00 litres (2.91 US gallons) |
| Other specifications | |
| Starter | Electric |
| Update specs | Report missing specs or required updates. |
