General information |
Motorcycle name
|
Honda TMX 155 |
Year of manufacture
|
2013 |
Type
|
Allround |
Rating
|
3.7 Check out the detailed rating of reliability, maintenance costs, value for money, etc. Compare with any other motorcycle. |
Engine and transmission |
Engine size
|
155.3 ccm (9.48 cubic inches) |
Type of engine
|
Single cylinder, four-stroke |
Output
|
12.5 HP (9.1 kW)) @ 8000 RPM |
Torque
|
12.1 Nm (1.2 kgf-m or 8.9 ft.lbs) @ 6500 RPM |
Compression
|
9.0:1 |
Bore x stroke
|
58.5 x 57.8 mm (2.3 x 2.3 inches) |
Fuel system
|
Carburettor |
Fuel control
|
Overhead Valves (OHV) |
Ignition
|
AC-CDI (Capacitor Discharge Ignition) |
Cooling system
|
Air |
Gearbox
|
4-speed |
Transmission type
|
Chain (final drive) |
Chassis, suspension, brakes and wheels |
Front suspension
|
Telescopic Fork |
Rear suspension
|
Twin shocks |
Front tire
|
3.00-17 |
Rear tire
|
3.00-17 |
Front brakes
|
Expanding brake (drum brake) |
Rear brakes
|
Expanding brake (drum brake) |
Wheels
|
Spoke |
Physical measures and capacities |
Dry weight
|
108.3 kg (238.8 pounds) |
Power/weight ratio
|
0.1151 HP/kg |
Seat height
|
743 mm (29.3 inches) If adjustable, lowest setting. |
Overall height
|
1032 mm (40.6 inches) |
Overall length
|
1915 mm (75.4 inches) |
Overall width
|
735 mm (28.9 inches) |
Ground clearance
|
150 mm (5.9 inches) |
Wheelbase
|
1201 mm (47.3 inches) |
Fuel capacity
|
9.00 litres (2.38 US gallons) |
Oil capacity
|
1.00 litres (1.06 US quarts) |
Other specifications |
Color options
|
Black, blue red |
Starter
|
Kick |
Comments
|
Sold in some Asian contries. |
