Honda's profilation of this bike |
The ST1300 ABS. Everything its non-ABS sibling is—longitudinally mounted V-4 engine, lightweight aluminum chassis, slick five-speed transmission, detachable, locking saddlebags and motorized, adjustable windshield—with the added performance of an anti-lock braking system. |
General information |
Model
|
Honda ST 1300 ABS |
Year
|
2005 |
Category
|
Sport touring |
Price as new | US$ 14799. MSRP depends on country, taxes, accessories, etc. |
Rating
|
3.8 See the detailed rating of touring capabilities, reliability, accident risk, etc. Compare with any other motorbike. |
Engine and transmission |
Displacement
|
1261.0 ccm (76.95 cubic inches) |
Engine type
|
V4, four-stroke |
Power
|
118.0 HP (86.1 kW)) @ 8000 RPM |
Torque
|
117.0 Nm (11.9 kgf-m or 86.3 ft.lbs) @ 6500 RPM |
Compression
|
10.8:1 |
Bore x stroke
|
78.0 x 66.0 mm (3.1 x 2.6 inches) |
Fuel system
|
Injection. Programmed Fuel Injection (PGM-FI) with automatic enricher circuit |
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
Ignition
|
Computer-controlled digital with three-dimensional mapping and electronic advance |
Cooling system
|
Liquid |
Gearbox
|
5-speed |
Transmission type
|
Shaft drive (cardan) (final drive) |
Chassis, suspension, brakes and wheels |
Frame type
|
Front Suspension |
Rake (fork angle)
|
26.0° |
Trail
|
98 mm (3.9 inches) |
Front suspension
|
45.0mm HMAS cartridge fork |
Front wheel travel
|
117 mm (4.6 inches) |
Rear suspension
|
HMAS gas-charged single shock with five-position spring-preload adjustability; |
Rear wheel travel
|
122 mm (4.8 inches) |
Front tire
|
120/70-ZR18 |
Rear tire
|
170/60-ZR17 |
Front brakes
|
Double disc. LBS 3-piston calipers. Anti-lock Braking System (ABS). |
Diameter
|
310 mm (12.2 inches) |
Rear brakes
|
Single disc. LBS 3-piston calipers. Anti-lock Braking System (ABS). |
Diameter
|
316 mm (12.4 inches) |
Physical measures and capacities |
Dry weight
|
288.9 kg (637.0 pounds) |
Power/weight ratio
|
0.4084 HP/kg |
Seat height
|
790 mm (31.1 inches) If adjustable, lowest setting. |
Wheelbase
|
1491 mm (58.7 inches) |
Fuel capacity
|
29.14 litres (7.70 US gallons) |
Other specifications |
Color options
|
Candy Dark Red |
Starter
|
Electric |
Comments
|
Model ID: ST1300A |
