Honda Shadow VTX Deluxe 20052005 Honda Shadow VTX Deluxe specifications, pictures, reviews and rating |
2005 Honda Shadow VTX Deluxe. Image credits - Honda.
| Honda's profilation of this bike |
| It´s the epitome of classic cruiser styling. Hardtail styled rear suspension. Spoked wheels. Low pavement-skimming seat. And chrome? Just about everywhere you look. The Shadow VLX Deluxe is cruiser you´ve been waiting for. |
| General information | |
|---|---|
| Model name | Honda Shadow VTX Deluxe |
| Model year | 2005 |
| Category | Custom / cruiser |
| Price as new | US$ 5399. MSRP depends on country, taxes, accessories, etc. |
| Rating | 3.6 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
| Engine and transmission | |
| Displacement | 583.0 ccm (35.57 cubic inches) |
| Engine type | V2, four-stroke |
| Compression | 9.2:1 |
| Bore x stroke | 75.0 x 66.0 mm (3.0 x 2.6 inches) |
| Fuel system | Carburettor. Single 34mm diaphragm-type CV |
| Fuel control | Single Overhead Cams (SOHC) |
| Ignition | CD with electronic advance, two spark plugs per cylinder |
| Cooling system | Liquid |
| Gearbox | 4-speed |
| Transmission type | Chain (final drive) |
| Chassis, suspension, brakes and wheels | |
| Rake (fork angle) | 32.7° |
| Trail | 161 mm (6.3 inches) |
| Front suspension | 39mm fork; |
| Front wheel travel | 145 mm (5.7 inches) |
| Rear suspension | Single-shock with seven-position spring-preload adjustability; |
| Rear wheel travel | 89 mm (3.5 inches) |
| Front tire | 100/90-19 |
| Rear tire | 170/80-15 |
| Front brakes | Single disc. 2-piston calipers. |
| Rear brakes | Expanding brake (drum brake) |
| Physical measures and capacities | |
| Dry weight | 207.7 kg (458.0 pounds) |
| Seat height | 650 mm (25.6 inches) If adjustable, lowest setting. |
| Wheelbase | 1600 mm (63.0 inches) |
| Fuel capacity | 10.97 litres (2.90 US gallons) |
| Other specifications | |
| Color options | Candy Orange, Pearl Blue, Pearl White |
| Starter | Electric |
| Comments | Model ID: VTX600CD |
| Update specs | Report missing specs or required updates. |
| Further information | |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 05 Honda Shadow VTX Deluxe discussion group or the general Honda discussion group. |
| Related bikes | List related bikes for comparison of specs. |
| Compare with another motorcycle | |
Discussions for every bike
Bikez has discussion forums for every bike. View comments, questions and answers at the 2005 Honda Shadow VTX Deluxe discussion group. You can sign up for e-mail notifications when other riders answer you. If you have extensive experience with the MC, please send us a review. If you consider buying this bike, you should view the list of related motorbikes Look at photos. Compare technical specs. And check out the rating of the bike's engine performance, reliability, repair costs, etc. You can compare the rating with other bikes.| Rating sample for this Honda bike | |
Value for money for the 2005 Honda Shadow VTX Deluxe:  (79.9 out of 100)Click here for complete rating. |
|
