Honda's profilation of this bike |
Its cast-aluminum wheels deliver 1100ccs of chrome-polished V-twin power to the asphalt. The classic Shadow Sabre is definitive proof that beauty isn´t just skin deep. |
General information |
Motorcycle name
|
Honda Shadow Sabre |
Year of manufacture
|
2005 |
Type
|
Custom / cruiser |
Price as new | US$ 8299. MSRP depends on country, taxes, accessories, etc. |
Rating
|
3.9 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
Engine and transmission |
Engine size
|
1099.0 ccm (67.06 cubic inches) |
Type of engine
|
V2, four-stroke |
Compression
|
8.0:1 |
Bore x stroke
|
87.5 x 91.4 mm (3.4 x 3.6 inches) |
Fuel system
|
Carburettor. Two 36mm CV |
Fuel control
|
Single Overhead Cams (SOHC) |
Ignition
|
Digital, two spark plugs per cylinder |
Cooling system
|
Liquid |
Gearbox
|
5-speed |
Transmission type
|
Shaft drive (cardan) (final drive) |
Chassis, suspension, brakes and wheels |
Frame type
|
Front Suspension |
Rake (fork angle)
|
32.7° |
Trail
|
161 mm (6.3 inches) |
Front suspension
|
41mm fork |
Front wheel travel
|
119 mm (4.7 inches) |
Rear suspension
|
Dual shocks with five-position spring-preload adjustability |
Rear wheel travel
|
99 mm (3.9 inches) |
Front tire
|
120/90-18 |
Rear tire
|
170/80-15 |
Front brakes
|
Single disc. 2-piston calipers. |
Diameter
|
316 mm (12.4 inches) |
Rear brakes
|
Single disc. 1-piston calipers. |
Diameter
|
276 mm (10.9 inches) |
Physical measures and capacities |
Dry weight
|
259.9 kg (573.0 pounds) |
Seat height
|
691 mm (27.2 inches) If adjustable, lowest setting. |
Wheelbase
|
1641 mm (64.6 inches) |
Fuel capacity
|
15.89 litres (4.20 US gallons) |
Other specifications |
Color options
|
Black, Black/Flame |
Starter
|
Electric |
Comments
|
Model ID: VT1100C2 |
