General information |
|
Model
|
Honda CT 125 |
|
Model year
|
1977 |
|
Category
|
Enduro / offroad |
|
Rating
|
3.5 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
124.0 ccm (7.57 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Top speed
|
91.7 km/h (57.0 mph) |
|
Compression
|
8.0:1 |
|
Bore x stroke
|
56.5 x 49.5 mm (2.2 x 1.9 inches) |
|
Fuel system
|
Carburettor |
|
Ignition
|
Kick |
|
Cooling system
|
Air |
|
Gearbox
|
5-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Manual |
|
Exhaust system
|
Single black exaust |
|
Chassis, suspension, brakes and wheels |
|
Rake (fork angle)
|
28.7° |
|
Trail
|
110 mm (4.3 inches) |
|
Front suspension
|
Inverted Forks |
|
Rear suspension
|
Twin Rear Spring |
|
Front tire
|
3.00-19 |
|
Rear tire
|
4.00-18 |
|
Front brakes
|
Expanding brake (drum brake) |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Physical measures and capacities |
|
Dry weight
|
108.0 kg (238.1 pounds) |
|
Seat height
|
813 mm (32.0 inches) If adjustable, lowest setting. |
|
Alternate seat height
|
813 mm (32.0 inches) If adjustable, highest setting. |
|
Overall height
|
1100 mm (43.3 inches) |
|
Overall length
|
2035 mm (80.1 inches) |
|
Overall width
|
900 mm (35.4 inches) |
|
Wheelbase
|
1295 mm (51.0 inches) |
|
Fuel capacity
|
6.05 litres (1.60 US gallons) |
|
Reserve fuel capacity
|
1.51 litres (0.40 US gallons) |
|
Other specifications |
|
Color options
|
Orange |
|
Starter
|
Kick |
|
Modifications compared to previous model
|
This Motorcycle was made for one year only. |
