Honda's profilation of this bike |
It´s hard knowing where to begin when describing the CRF230L. First and foremost, it´s a dirtbike that happens to be street-legal, so it has the goods—torquey 223cc single-cylinder engine, six-speed gearbox, lightweight chassis, Pro-Link® rear suspension, head- and taillights and turn signals—to take you anywhere, on-road or off. Add to that a low, confidence-inspiring seat height, no-fuss electric start and great gas mileage, and you´re looking at the perfect dual-sport machine for conquering your commute... or your favorite trail. |
General information |
Model
|
Honda CRF230L |
Year
|
2011 |
Category
|
Enduro / offroad |
Price as new | US$ 5399. MSRP depends on country, taxes, accessories, etc. |
Rating
|
3.6 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
Engine and transmission |
Displacement
|
223.0 ccm (13.61 cubic inches) |
Engine type
|
Single cylinder, four-stroke |
Torque
|
65.5 Nm (6.7 kgf-m or 48.3 ft.lbs) |
Compression
|
9.0:1 |
Bore x stroke
|
65.5 x 66.2 mm (2.6 x 2.6 inches) |
Fuel system
|
Carburettor. 30mm CV carbureto |
Fuel control
|
Single Overhead Cams (SOHC) |
Ignition
|
CD |
Cooling system
|
Air |
Gearbox
|
6-speed |
Transmission type
|
Chain (final drive) |
Driveline
|
#520 O-ring-sealed chain |
Emission details
|
Meets current CARB and EPA standards |
Chassis, suspension, brakes and wheels |
Rake (fork angle)
|
26.8° |
Trail
|
103 mm (4.1 inches) |
Front suspension
|
37mm leading-axle Showa fork |
Front wheel travel
|
229 mm (9.0 inches) |
Rear suspension
|
Pro-link Showa single shock with adjustable spring preload adjustability |
Rear wheel travel
|
160 mm (6.3 inches) |
Front tire
|
2.75-21 |
Rear tire
|
120/80-18 |
Front brakes
|
Single disc |
Diameter
|
240 mm (9.4 inches) |
Rear brakes
|
Single disc |
Diameter
|
220 mm (8.7 inches) |
Physical measures and capacities |
Dry weight
|
220.0 kg (485.0 pounds) |
Weight incl. oil, gas, etc
|
121.1 kg (267.0 pounds) |
Seat height
|
810 mm (31.9 inches) If adjustable, lowest setting. |
Ground clearance
|
241 mm (9.5 inches) |
Wheelbase
|
1340 mm (52.8 inches) |
Fuel capacity
|
8.71 litres (2.30 US gallons) |
Other specifications |
Color options
|
Red |
Starter
|
Electric |
Factory warranty
|
One year. Coverage of defects in materials and workmanship |
Comments
|
Model ID: CRF230L |
