Honda's profilation of this bike |
Throw your leg over the saddle of the CRF230F, push the electric starter, and have a blast. You don´t have to worry about breaking down or time-sapping maintenance—with a minimum of care, you can jump on the CRF230F with its durable six-speed transmission and plush, long travel suspension and leave the on-road world in the dust. |
General information |
Model name
|
Honda CRF230F |
Model year
|
2011 |
Category
|
Trial |
Price as new | US$ 3899. MSRP depends on country, taxes, accessories, etc. |
Rating
|
3.8 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
Engine and transmission |
Displacement
|
223.0 ccm (13.61 cubic inches) |
Engine type
|
Single cylinder, four-stroke |
Compression
|
9.0:1 |
Bore x stroke
|
65.5 x 66.2 mm (2.6 x 2.6 inches) |
Fuel system
|
Carburettor. 26mm piston-valve carburator |
Fuel control
|
Single Overhead Cams (SOHC) |
Ignition
|
CDI |
Cooling system
|
Air |
Gearbox
|
6-speed |
Transmission type
|
Chain (final drive) |
Driveline
|
#520 O-ring-sealed chain; 13T/50T |
Emission details
|
Meets current CARB and EPA standards. California version differs slightly due to emissions equipment. |
Chassis, suspension, brakes and wheels |
Rake (fork angle)
|
27.3° |
Trail
|
112 mm (4.4 inches) |
Front suspension
|
37mm leading-axle Showa fork |
Front wheel travel
|
241 mm (9.5 inches) |
Rear suspension
|
Pro-Link Showa single-shock with spring-preload adjustability |
Rear wheel travel
|
229 mm (9.0 inches) |
Front tire
|
80/100-21 |
Rear tire
|
100/100-18 |
Front brakes
|
Single disc |
Diameter
|
240 mm (9.4 inches) |
Rear brakes
|
Expanding brake (drum brake) |
Physical measures and capacities |
Weight incl. oil, gas, etc
|
112.9 kg (249.0 pounds) |
Seat height
|
866 mm (34.1 inches) If adjustable, lowest setting. |
Ground clearance
|
297 mm (11.7 inches) |
Wheelbase
|
1374 mm (54.1 inches) |
Fuel capacity
|
7.19 litres (1.90 US gallons) |
Other specifications |
Color options
|
Red |
Starter
|
Electric |
Comments
|
Model ID: CRF230F |
