General information |
Model
|
Honda CBF600F |
Year
|
2012 |
Category
|
Naked bike |
Rating
|
3.5 See the detailed rating of engine performance, design and look, accident risk, etc. Compare with any other motorcycle. |
Engine and transmission |
Displacement
|
599.0 ccm (36.55 cubic inches) |
Engine type
|
In-line four, four-stroke |
Power
|
100.6 HP (73.4 kW)) @ 12000 RPM |
Torque
|
63.5 Nm (6.5 kgf-m or 46.8 ft.lbs) @ 10500 RPM |
Compression
|
12.0:1 |
Bore x stroke
|
67.0 x 42.5 mm (2.6 x 1.7 inches) |
Valves per cylinder
|
4 |
Fuel system
|
Injection. PGM-FI |
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
Ignition
|
Computer-controlled digital transistorised with electronic advanceĀ |
Cooling system
|
Liquid |
Gearbox
|
6-speed |
Transmission type
|
Chain (final drive) |
Driveline
|
#525 O-ring sealed chainĀ |
Chassis, suspension, brakes and wheels |
Rake (fork angle)
|
25.0° |
Trail
|
99 mm (3.9 inches) |
Front suspension
|
41mm inverted telescopic fork |
Front wheel travel
|
120 mm (4.7 inches) |
Rear suspension
|
Monoshock damper with 7-step adjustable preload |
Rear wheel travel
|
128 mm (5.0 inches) |
Front tire
|
120/70-ZR17 |
Rear tire
|
180/55-ZR17 |
Front brakes
|
Double disc. Optional ABS. Twin piston caliper. |
Diameter
|
296 mm (11.7 inches) |
Rear brakes
|
Single disc. Optional ABS |
Diameter
|
240 mm (9.4 inches) |
Wheels
|
Hollow-section 5-spoke cast aluminium |
Physical measures and capacities |
Dry weight
|
172.0 kg (379.2 pounds) |
Power/weight ratio
|
0.5848 HP/kg |
Seat height
|
800 mm (31.5 inches) If adjustable, lowest setting. |
Overall height
|
1095 mm (43.1 inches) |
Overall length
|
2090 mm (82.3 inches) |
Overall width
|
740 mm (29.1 inches) |
Ground clearance
|
135 mm (5.3 inches) |
Wheelbase
|
1435 mm (56.5 inches) |
Fuel capacity
|
19.00 litres (5.02 US gallons) |
Reserve fuel capacity
|
3.50 litres (0.92 US gallons) |
Other specifications |
Starter
|
Electric |
Comments
|
Called Honda 599 in the US. |
