Honda CB 750 F 2 19781978 Honda CB 750 F 2 specifications, pictures, reviews and rating |
| General information | |
|---|---|
| Model name | Honda CB 750 F 2 |
| Year | 1978 |
| Category | Scooter |
| Rating | 3.2 View the detailed rating of value for money, design and look, reliability, etc. Compare with any other bike. |
| Engine and transmission | |
| Displacement | 736.0 ccm (44.91 cubic inches) |
| Engine type | In-line four, four-stroke |
| Power | 73.0 HP (53.3 kW)) @ 9000 RPM |
| Torque | 62.4 Nm (6.4 kgf-m or 46.0 ft.lbs) @ 7500 RPM |
| Top speed | 197.0 km/h (122.4 mph) |
| Compression | 9.0:1 |
| Bore x stroke | 61.0 x 63.0 mm (2.4 x 2.5 inches) |
| Valves per cylinder | 2 |
| Fuel system | Carburettor. 28mm Keihin |
| Fuel control | Single Overhead Cams (SOHC) |
| Ignition | CDI |
| Cooling system | Air |
| Gearbox | 5-speed |
| Transmission type | Chain (final drive) |
| Fuel consumption | 5.19 litres/100 km (19.3 km/l or 45.32 mpg) |
| Greenhouse gases | 120.4 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Chassis, suspension, brakes and wheels | |
| Front suspension | Telehydraulic forks |
| Rear suspension | Swingarm with 5-way spring preload adjustment. |
| Front tire | 3.25-19 |
| Rear tire | 4.00-18 |
| Front brakes | Double disc |
| Diameter | 276 mm (10.9 inches) |
| Rear brakes | Single disc |
| Diameter | 296 mm (11.7 inches) |
| Physical measures and capacities | |
| Dry weight | 233.0 kg (513.7 pounds) |
| Weight incl. oil, gas, etc | 253.0 kg (557.8 pounds) |
| Power/weight ratio | 0.3133 HP/kg |
| Seat height | 830 mm (32.7 inches) If adjustable, lowest setting. |
| Fuel capacity | 18.00 litres (4.76 US gallons) |
| Other specifications | |
| Starter | Electric |
| Update specs | Report missing specs or required updates. |
