Honda CB 500 19991999 Honda CB 500 specifications, pictures, reviews and rating |
| General information | |
|---|---|
| Model name | Honda CB 500 |
| Year model | 1999 |
| Type | Naked bike |
| Rating | 3.0 See the detailed rating of engine performance, design and look, accident risk, etc. Compare with any other motorcycle. |
| Engine and transmission | |
| Engine size | 499.0 ccm (30.45 cubic inches) |
| Type of engine | Twin, four-stroke |
| Effect | 57.0 HP (41.6 kW)) @ 9500 RPM |
| Torque | 34.7 Nm (3.5 kgf-m or 25.6 ft.lbs) @ 8000 RPM |
| Top speed | 193.0 km/h (119.9 mph) |
| 1/4 mile (0.4 km) | 13.50 seconds |
| Maximum RPM | 10500 |
| Valves per cylinder | 4 |
| Fuel system | Carburettor. Keihin 2 x 34 mm VP type |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Ignition | Digital transistorised with electronic advance |
| Cooling system | Liquid |
| Gearbox | 6-speed |
| Transmission type | Chain (final drive) |
| Clutch | Wet multi-plate, calbe-operated |
| Fuel consumption | 5.50 litres/100 km (18.2 km/l or 42.77 mpg) |
| Greenhouse gases | 127.6 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Chassis, suspension, brakes and wheels | |
| Frame type | Double cradle of tubular and box-section steel construction |
| Rake (fork angle) | 27.0° |
| Trail | 113 mm (4.4 inches) |
| Front suspension | 37 mm oil-damped telescopic forks |
| Front wheel travel | 115 mm (4.5 inches) |
| Rear suspension | Twin shoks acting on a steel, box-section swingarm |
| Rear wheel travel | 117 mm (4.6 inches) |
| Front tire | 110/80-17 57H |
| Rear tire | 130/80-17 65H |
| Front brakes | Single disc. Nissin 2-piston sliding caliper |
| Diameter | 296 mm (11.7 inches) |
| Rear brakes | Single disc. Brembo single piston sliding caliper |
| Diameter | 240 mm (9.4 inches) |
| Physical measures and capacities | |
| Dry weight | 173.0 kg (381.4 pounds) |
| Power/weight ratio | 0.3295 HP/kg |
| Seat height | 775 mm (30.5 inches) If adjustable, lowest setting. |
| Overall height | 1050 mm (41.3 inches) |
| Overall length | 2090 mm (82.3 inches) |
| Overall width | 720 mm (28.3 inches) |
| Ground clearance | 145 mm (5.7 inches) |
| Wheelbase | 1435 mm (56.5 inches) |
| Fuel capacity | 18.00 litres (4.76 US gallons) |
| Reserve fuel capacity | 2.50 litres (0.66 US gallons) |
| Oil capacity | 3.10 litres (3.28 US quarts) |
| Other specifications | |
| Starter | Electric |
| Update specs | Report missing specs or required updates. |
| Further information | |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Parts finder | CMSNL provides
online schematics & OEM parts |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 99 Honda CB 500 discussion group or the general Honda discussion group. |
| Related bikes | List related bikes for comparison of specs. |
| Compare with another motorcycle | |
Discussions for every bike
Bikez has discussion forums for every bike. View comments, questions and answers at the 1999 Honda CB 500 discussion group. You can sign up for e-mail notifications when other riders answer you. If you have extensive experience with the MC, please send us a review. If you consider buying this bike, you should view the list of related motorbikes Look at photos. Compare technical specs. And check out the rating of the bike's engine performance, reliability, repair costs, etc. You can compare the rating with other bikes.| Rating sample for this Honda bike | |
Engine performance for the 1999 Honda CB 500:  (71.0 out of 100)Click here for complete rating. |
|
