| Highland's profilation of this bike |
| The ultra-light 60-degree 950 cc V2 engine is designed and developed by motorcycle enthusiasts with over 100 years of tradition in building motorcycles.
|
|
General information |
|
Motorcycle name
|
Highland DirtTrac 950 |
|
Year model
|
2009 |
|
Type
|
Trial |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
950.0 ccm (57.97 cubic inches) |
|
Type of engine
|
V2, four-stroke |
|
Effect
|
85.0 HP (62.0 kW)) @ 6000 RPM |
|
Torque
|
104.0 Nm (10.6 kgf-m or 76.7 ft.lbs) @ 4000 RPM |
|
Top speed
|
200.0 km/h (124.3 mph) |
|
Compression
|
11.5:1 |
|
Bore x stroke
|
95.0 x 66.0 mm (3.7 x 2.6 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Injection |
|
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
|
Ignition
|
i2 Highland integrated engine management system with ignition coils fitted directly on the spark plugs |
|
Lubrication system
|
Wet sump, double filter, pressure lubricated crankshaft, camshaft and gearbox |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Wet multidisk |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
CrMo steel |
|
Front suspension
|
Kayaba fork |
|
Rear suspension
|
Penske shocks |
|
Front tire
|
120/70-17 |
|
Rear tire
|
160/60-17 |
|
Front brakes
|
Single disc. Beringer six piston caliper |
|
Diameter
|
310 mm (12.2 inches) |
|
Rear brakes
|
Single disc. Brembo caliper |
|
Diameter
|
220 mm (8.7 inches) |
|
Physical measures and capacities |
|
Dry weight
|
129.0 kg (284.4 pounds) |
|
Power/weight ratio
|
0.6589 HP/kg |
|
Seat height
|
720 mm (28.3 inches) If adjustable, lowest setting. |
|
Wheelbase
|
1400 mm (55.1 inches) |
|
Fuel capacity
|
10.00 litres (2.64 US gallons) |
|
Other specifications |
|
Color options
|
Yellow/black |
|
Starter
|
Electric |
