General information |
|
Motorcycle name
|
Highland DirtTrac |
|
Year model
|
2006 |
|
Type
|
Super motard |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. |
|
Engine and transmission |
|
Engine size
|
749.0 ccm (45.70 cubic inches) |
|
Type of engine
|
V2, four-stroke |
|
Effect
|
83.8 HP (61.2 kW)) @ 7000 RPM |
|
Torque
|
84.0 Nm (8.6 kgf-m or 62.0 ft.lbs) @ 5000 RPM |
|
Top speed
|
200.0 km/h (124.3 mph) |
|
Compression
|
11.5:1 |
|
Bore x stroke
|
95.0 x 53.0 mm (3.7 x 2.1 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Injection. Highland integrated engine management system with ignition coils fitted directly on the spark plugs |
|
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
|
Lubrication system
|
Wet sump |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Rectangular section, CrMo steel and aluminum (7021-T6) swing arm |
|
Rake (fork angle)
|
25.0° |
|
Front suspension
|
Showa |
|
Rear suspension
|
Pensky |
|
Front tire
|
120/70-17 |
|
Rear tire
|
160/60-17 |
|
Front brakes
|
Single disc. Bremo |
|
Diameter
|
320 mm (12.6 inches) |
|
Rear brakes
|
Single disc. Bremo |
|
Diameter
|
260 mm (10.2 inches) |
|
Physical measures and capacities |
|
Dry weight
|
129.0 kg (284.4 pounds) |
|
Power/weight ratio
|
0.6497 HP/kg |
|
Seat height
|
720 mm (28.3 inches) If adjustable, lowest setting. |
|
Wheelbase
|
1400 mm (55.1 inches) |
|
Fuel capacity
|
8.50 litres (2.25 US gallons) |
|
Other specifications |
|
Starter
|
Electric |
