| Highland's profilation of this bike |
| Legendary power wrapped in a lightweight package. |
|
General information |
|
Model name
|
Highland 950cc Street Tracker |
|
Year of manufacture
|
2011 |
|
Type
|
Allround |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. |
|
Engine and transmission |
|
Engine size
|
950.0 ccm (57.97 cubic inches) |
|
Type of engine
|
V2, four-stroke |
|
Engine details
|
60 degree V-engine |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Injection. EFI, fully adjustable |
|
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
|
Lubrication system
|
Wet sump |
|
Cooling system
|
Liquid |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Wet, multiplate |
|
Driveline
|
6-speed constant mesh |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
CroMo tubular spaceframe |
|
Front suspension
|
Telescopic fork |
|
Front wheel travel
|
300 mm (11.8 inches) |
|
Rear suspension
|
PDS |
|
Rear wheel travel
|
274 mm (10.8 inches) |
|
Front tire
|
120/70-17 |
|
Rear tire
|
160/70-17 |
|
Front brakes
|
Single disc. 6-piston calipers |
|
Diameter
|
310 mm (12.2 inches) |
|
Rear brakes
|
Single disc. Single piston calipers |
|
Diameter
|
221 mm (8.7 inches) |
|
Physical measures and capacities |
|
Seat height
|
770 mm (30.3 inches) If adjustable, lowest setting. |
|
Ground clearance
|
185 mm (7.3 inches) |
|
Wheelbase
|
1405 mm (55.3 inches) |
|
Fuel capacity
|
7.57 litres (2.00 US gallons) |
|
Other specifications |
|
Color options
|
Yellow/black |
|
Starter
|
Electric |
|
Modifications compared to previous model
|
USHighland also used as brand name. |
