Hero Honda's profilation of this bike |
Awesome all black engine. Fascinating new graphics. |
General information |
Motorcycle name
|
Hero Honda Passion Plus |
Year model
|
2011 |
Type
|
Sport |
Rating
|
3.4 Check out the detailed rating of racing track capabilities, engine performance, accident risk, etc. Compare with any other bike. |
Engine and transmission |
Engine size
|
97.5 ccm (5.95 cubic inches) |
Type of engine
|
Single cylinder, four-stroke |
Effect
|
7.4 HP (5.4 kW)) @ 8000 RPM |
Torque
|
8.0 Nm (0.8 kgf-m or 5.9 ft.lbs) @ 5000 RPM |
Compression
|
9.0:1 |
Bore x stroke
|
50.0 x 49.5 mm (2.0 x 1.9 inches) |
Fuel system
|
Carburettor |
Fuel control
|
Overhead Cams (OHC) |
Ignition
|
CDI |
Cooling system
|
Air |
Transmission type
|
Chain (final drive) |
Clutch
|
Multiplate, wet |
Driveline
|
4-speed constant mesh |
Chassis, suspension, brakes and wheels |
Frame type
|
Tubular double cradle |
Front suspension
|
Telescopic hydraulic shock absorbers |
Rear suspension
|
Swing arm with adjustable hydraulic shock absorbers |
Front tire
|
2.75-18 |
Rear tire
|
3.00-18 |
Front brakes
|
Expanding brake (drum brake) |
Diameter
|
130 mm (5.1 inches) |
Rear brakes
|
Expanding brake (drum brake) |
Diameter
|
130 mm (5.1 inches) |
Wheels
|
Alloy wheels |
Physical measures and capacities |
Dry weight
|
116.0 kg (255.7 pounds) |
Weight incl. oil, gas, etc
|
127.0 kg (280.0 pounds) |
Power/weight ratio
|
0.0635 HP/kg |
Overall length
|
1980 mm (78.0 inches) |
Overall width
|
720 mm (28.3 inches) |
Ground clearance
|
159 mm (6.3 inches) |
Wheelbase
|
1235 mm (48.6 inches) |
Fuel capacity
|
12.80 litres (3.38 US gallons) |
Reserve fuel capacity
|
1.10 litres (0.29 US gallons) |
Other specifications |
Color options
|
Red, blue, black, silver, maroon |
Starter
|
Kick |
Electrical
|
12Volt 2.5 Ah battery |
Light
|
35W/35W halogen bulb. Multireflector. |
Comments
|
Bike sold in India. |
Update specs | Report missing specs or required updates. |
Further information |
Insurance costs | Compare US insurance quotes from the nation's top providers. |
Parts finder |
Check out our overview of motorcycle webshops at Bikez.info. |
Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
Ask questions | Join the 11 Hero Honda Passion Plus discussion group or the general Hero Honda discussion group. |
Related bikes | List related bikes for comparison of specs. |
|
Rating sample for this Hero Honda bike
|
Engine performance for the 2011 Hero Honda Passion Plus:
(66.1 out of 100)
Click here for complete rating. You can also compare bikes.
|
|
