Hero Honda's profilation of this bike |
A smooth ride over the toughest of roads with maximum fuel efficiency and at an affordable price, now you can bid goodbye to all your commuting problems!
|
General information |
Motorcycle name
|
Hero Honda CD Dawn |
Model year
|
2006 |
Category
|
Sport |
Rating
|
3.4 Check out the detailed rating of racing track capabilities, engine performance, accident risk, etc. Compare with any other bike. |
Engine and transmission |
Displacement
|
97.2 ccm (5.93 cubic inches) |
Engine type
|
Single cylinder, four-stroke |
Power output
|
9.9 HP (7.2 kW)) @ 8000 RPM |
Torque
|
7.9 Nm (0.8 kgf-m or 5.8 ft.lbs) @ 5000 RPM |
Compression
|
8.8:1 |
Bore x stroke
|
50.0 x 49.5 mm (2.0 x 1.9 inches) |
Fuel system
|
Carburettor |
Fuel control
|
Overhead Cams (OHC) |
Ignition
|
Electronic |
Cooling system
|
Air |
Gearbox
|
4-speed |
Transmission type
|
Chain (final drive) |
Clutch
|
Multiplate wet |
Chassis, suspension, brakes and wheels |
Frame type
|
Tubular double cradle |
Front suspension
|
Telescopic hydraulic shock absorber |
Rear suspension
|
Swing arm with hydraulic shock absorber |
Front tire
|
2.75-18 |
Rear tire
|
2.75-18 |
Front brakes
|
Expanding brake (drum brake) |
Rear brakes
|
Expanding brake (drum brake) |
Physical measures and capacities |
Weight incl. oil, gas, etc
|
108.0 kg (238.1 pounds) |
Overall height
|
1045 mm (41.1 inches) |
Overall length
|
1980 mm (78.0 inches) |
Overall width
|
720 mm (28.3 inches) |
Ground clearance
|
150 mm (5.9 inches) |
Wheelbase
|
1230 mm (48.4 inches) |
Fuel capacity
|
10.50 litres (2.77 US gallons) |
Other specifications |
Starter
|
Kick |
Update specs | Report missing specs or required updates. |
Further information |
Insurance costs | Compare US insurance quotes from the nation's top providers. |
Parts finder |
Check out our overview of motorcycle webshops at Bikez.info. |
Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
Ask questions | Join the 06 Hero Honda CD Dawn discussion group or the general Hero Honda discussion group. |
Related bikes | List related bikes for comparison of specs. |
|
Rating sample for this Hero Honda bike
|
Touring capabilities for the 2006 Hero Honda CD Dawn:
(59.3 out of 100)
Click here for complete rating. You can also compare bikes.
|
|
