| Harley-Davidson's profilation of this bike |
| First came the original XR1200®. Designed with the European rider in mind, it demonstrates agility and focus not traditionally found on a Harley-Davidson® motorcycle. The distinctive paint job and retro graphics echo its dirt bike heritage, while the flat track style speedo, exhaust, tail section and wheels are suitably refined for modern roads. |
|
General information |
|
Model name
|
Harley-Davidson XR1200X |
|
Year
|
2010 |
|
Category
|
Sport |
|
Rating
|
3.6 Check out the detailed rating of racing track capabilities, engine performance, accident risk, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
1202.0 ccm (73.35 cubic inches) |
|
Engine type
|
V2, four-stroke |
|
Power
|
90.0 HP (65.7 kW)) @ 7000 RPM |
|
Torque
|
100.0 Nm (10.2 kgf-m or 73.8 ft.lbs) @ 3700 RPM |
|
Compression
|
10.0:1 |
|
Bore x stroke
|
88.9 x 96.8 mm (3.5 x 3.8 inches) |
|
Valves per cylinder
|
2 |
|
Fuel system
|
Injection. ESPFI |
|
Fuel control
|
Overhead Valves (OHV) |
|
Cooling system
|
Air |
|
Gearbox
|
5-speed |
|
Transmission type
|
Belt (final drive) |
|
Clutch
|
8-plate, wet |
|
Exhaust system
|
Upswept, high-volume 2-1-2 straight shot in Black Denim |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Mild steel tubular frame; circular sections; cast junctions |
|
Rake (fork angle)
|
29.3° |
|
Trail
|
130 mm (5.1 inches) |
|
Front suspension
|
43 mm inverted fork |
|
Rear suspension
|
Coil-over shocks, preload dual-adjustment |
|
Front tire
|
120/70-ZR18 |
|
Rear tire
|
180/55-ZR17 |
|
Front brakes
|
Double disc. Dual 4-piston |
|
Diameter
|
292 mm (11.5 inches) |
|
Rear brakes
|
Single disc. Single piston |
|
Diameter
|
260 mm (10.2 inches) |
|
Physical measures and capacities |
|
Dry weight
|
250.0 kg (551.2 pounds) |
|
Power/weight ratio
|
0.3600 HP/kg |
|
Seat height
|
765 mm (30.1 inches) If adjustable, lowest setting. |
|
Overall length
|
2195 mm (86.4 inches) |
|
Ground clearance
|
145 mm (5.7 inches) |
|
Wheelbase
|
1515 mm (59.6 inches) |
|
Fuel capacity
|
13.30 litres (3.51 US gallons) |
|
Oil capacity
|
2.50 litres (2.64 US quarts) |
|
Other specifications |
|
Color options
|
Black Denim |
|
Comments
|
Blacked-out styling including denim paint and black powertrain and exhaust;
Wide, low-rise handlebars for superb control; Downdraft Electronic Sequential
Port Fuel Injection (ESPFI) and electronically controlled active intake system;
Unique, lightweight cast wheels with flat track inspired 3-spoke design and
orange pinstripe; Powerful Nissin® dual front brakes; Dual floating rotors (front)
for improved braking performance; Specially developed Dunlop® Qualifier D209
tyres; Sport-tuned Showa® piggyback suspension featuring fully adjustable,
43mm inverted front forks and fully adjustable rear shocks; Unique compact
instruments; Aircraft style aluminium alloy fuel filler |
