| Harley-Davidson's profilation of this bike |
| With styling inspired by the legendary flat-track champion XR750, the XR1200™ is a Sportster® tuned to excel in all aspects of street performance in the hands of a capable, aggressive rider. |
|
General information |
|
Model
|
Harley-Davidson XR1200 |
|
Year model
|
2010 |
|
Type
|
Sport |
|
Rating
|
3.7 Check out the detailed rating of racing track capabilities, engine performance, accident risk, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
1202.0 ccm (73.35 cubic inches) |
|
Type of engine
|
V2, four-stroke |
|
Effect
|
90.0 HP (65.7 kW)) @ 7000 RPM |
|
Torque
|
100.0 Nm (10.2 kgf-m or 73.8 ft.lbs) @ 3700 RPM |
|
Compression
|
10.0:1 |
|
Bore x stroke
|
88.9 x 96.8 mm (3.5 x 3.8 inches) |
|
Valves per cylinder
|
2 |
|
Fuel system
|
Injection. Electronic Sequential Port Fuel Injection (ESPFI) |
|
Cooling system
|
Air |
|
Gearbox
|
5-speed |
|
Transmission type
|
Belt (final drive) |
|
Clutch
|
8-plate, wet |
|
Exhaust system
|
Upswept, high-volume 2-1-2 straight shot |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Mild steel tubular frame; circular sections; cast junctions |
|
Rake (fork angle)
|
29.3° |
|
Trail
|
130 mm (5.1 inches) |
|
Front suspension
|
43 mm inverted fork |
|
Rear suspension
|
Coil-over shocks |
|
Front tire
|
120/70-ZR18 |
|
Rear tire
|
180/55-ZR17 |
|
Front brakes
|
Double disc. Dual 4-piston |
|
Diameter
|
292 mm (11.5 inches) |
|
Rear brakes
|
Single disc. Single piston |
|
Diameter
|
260 mm (10.2 inches) |
|
Physical measures and capacities |
|
Dry weight
|
250.0 kg (551.2 pounds) |
|
Power/weight ratio
|
0.3600 HP/kg |
|
Seat height
|
765 mm (30.1 inches) If adjustable, lowest setting. |
|
Overall length
|
2195 mm (86.4 inches) |
|
Ground clearance
|
145 mm (5.7 inches) |
|
Wheelbase
|
1515 mm (59.6 inches) |
|
Fuel capacity
|
13.30 litres (3.51 US gallons) |
|
Oil capacity
|
2.50 litres (2.64 US quarts) |
|
Other specifications |
|
Color options
|
Vivid Black, Mirage Orange Pearl, Brilliant Silver Denim |
|
Starter
|
Electric |
|
Comments
|
Wide, black handlebars for dirt track looks and superb control; Downdraft
Electronic Sequential Port Fuel Injection (ESPFI) and electronically controlled
active intake system; Unique, lightweight cast wheels with flat track inspired
3-spoke design; Powerful Nissin® dual front brakes with four piston front and
single-piston floating rear calipers, and 292mm (front) / 260mm (rear) patented
uniform expansion rotors; Specially developed Dunlop® Qualifier D209 tyres;
Sport-tuned Showa® suspension featuring 43mm inverted front forks and
pre-load adjustable twin rear shock absorbers; Unique compact instruments;
Aircraft style aluminium alloy fuel fil |
