Harley-Davidson XLH Sportster 1200 19891989 Harley-Davidson XLH Sportster 1200 specifications, pictures, reviews and rating |
| General information | |
|---|---|
| Model | Harley-Davidson XLH Sportster 1200 |
| Year | 1989 |
| Category | Custom / cruiser |
| Rating | 3.5 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
| Engine and transmission | |
| Displacement | 1198.0 ccm (73.10 cubic inches) |
| Engine type | V2, four-stroke |
| Power | 58.0 HP (42.3 kW)) @ 5200 RPM |
| Top speed | 177.0 km/h (110.0 mph) |
| Compression | 9.0:1 |
| Bore x stroke | 88.8 x 96.8 mm (3.5 x 3.8 inches) |
| Valves per cylinder | 2 |
| Fuel system | Carburettor |
| Fuel control | Overhead Valves (OHV) |
| Ignition | Points |
| Cooling system | Air |
| Gearbox | 4-speed |
| Transmission type | Belt (final drive) |
| Fuel consumption | 4.70 litres/100 km (21.3 km/l or 50.05 mpg) |
| Greenhouse gases | 109.0 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Chassis, suspension, brakes and wheels | |
| Frame type | Tubular duplex steel cradle |
| Front suspension | Telescopic fork |
| Rear suspension | Twin shocks with 5 position adjustment |
| Front tire | MJ 90-19 |
| Rear tire | MT 90-16 |
| Front brakes | Single disc |
| Rear brakes | Single disc |
| Physical measures and capacities | |
| Weight incl. oil, gas, etc | 222.0 kg (489.4 pounds) |
| Seat height | 737 mm (29.0 inches) If adjustable, lowest setting. |
| Fuel capacity | 14.00 litres (3.70 US gallons) |
| Other specifications | |
| Update specs | Report missing specs or required updates. |
| Further information | |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Parts finder | Check out our overview of motorcycle webshops at Bikez.info. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 89 Harley-Davidson XLH Sportster 1200 discussion group or the general Harley-Davidson discussion group. |
| Related bikes | List related bikes for comparison of specs. |
| Compare with another motorcycle | |
Buying a bike starts at Bikez
Get a list of related motorbikes before you buy this Harley-Davidson. Inspect technical data. Look at photos. Read the riders' comments at the bike's discussion group. And check out the bike's reliability, repair costs, etc. Show any 1989 Harley-Davidson XLH Sportster 1200 for sale on our Bikez.biz Motorcycle Classifieds. You can also sign up for e-mail notification when such bikes are advertised in the future. And advertise your old MC for sale. Our efficient ads are free. You are also welcome to read and submit motorcycle reviews.| Rating sample for this Harley-Davidson bike | |
Reliability for the 1989 Harley-Davidson XLH Sportster 1200:  (66.7 out of 100)Click here for complete rating. |
|
