General information |
|
Model name
|
Harley-Davidson SX 175 |
|
Model year
|
1976 |
|
Category
|
Enduro / offroad |
|
Rating
|
2.8 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
174.0 ccm (10.62 cubic inches) |
|
Engine type
|
Single cylinder, two-stroke |
|
Power output
|
17.0 HP (12.4 kW)) @ 6750 RPM |
|
Top speed
|
113.0 km/h (70.2 mph) |
|
Compression
|
10.7:1 |
|
Bore x stroke
|
61.0 x 59.6 mm (2.4 x 2.3 inches) |
|
Fuel control
|
Port control |
|
Cooling system
|
Air |
|
Gearbox
|
5-speed |
|
Transmission type
|
Chain (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Front tire
|
3.00-19 |
|
Rear tire
|
3.50-18 |
|
Front brakes
|
Expanding brake |
|
Rear brakes
|
Expanding brake |
|
Physical measures and capacities |
|
Weight incl. oil, gas, etc
|
127.0 kg (280.0 pounds) |
|
Fuel capacity
|
10.50 litres (2.77 US gallons) |
|
Other specifications |
| Update specs | Report missing specs or required updates. |
|
Further information |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Parts finder |
Check out our overview of motorcycle webshops at Bikez.info. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 76 Harley-Davidson SX 175 discussion group or the general Harley-Davidson discussion group. |
| Related bikes | List related bikes for comparison of specs. |
|
|
|
Rating sample for this Harley-Davidson bike
|
Touring capabilities for the 1976 Harley-Davidson SX 175:
 (39.5 out of 100)
Click here for complete rating. You can also compare bikes.
|
|
