General information |
|
Model name
|
Harley-Davidson Sportster Iron 883 Dark Custom |
|
Model year
|
2013 |
|
Category
|
Custom / cruiser |
| Price as new | US$ 7999. MSRP depends on country, taxes, accessories, etc. |
|
Rating
|
3.6 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
883.3 ccm (53.90 cubic inches) |
|
Engine type
|
V2, four-stroke |
|
Engine details
|
Air-cooled, Evolution® |
|
Torque
|
74.6 Nm (7.6 kgf-m or 55.0 ft.lbs) @ 3500 RPM |
|
Compression
|
8.9:1 |
|
Bore x stroke
|
76.2 x 96.8 mm (3.0 x 3.8 inches) |
|
Fuel system
|
Injection. Electronic Sequential Port Fuel Injection |
|
Cooling system
|
Air |
|
Gearbox
|
6-speed |
|
Transmission type
|
Belt (final drive) |
|
Clutch
|
Multi-plate with diaphragm spring in oil bath |
|
Driveline
|
Chain, 57/34 ratio primary drive |
|
Fuel consumption
|
4.61 litres/100 km (21.7 km/l or 51.02 mpg) |
|
Greenhouse gases
|
107.0 CO2 g/km. (CO2 - Carbon dioxide emission) |
|
Exhaust system
|
Chrome, staggered shorty exhaust with dual mufflers |
|
Chassis, suspension, brakes and wheels |
|
Rake (fork angle)
|
30.5° |
|
Trail
|
117 mm (4.6 inches) |
|
Front tire
|
100/90-B19 |
|
Rear tire
|
150/80-B16 |
|
Front brakes
|
Single disc. Dual-piston |
|
Rear brakes
|
Single disc |
|
Wheels
|
Black, 13-Spoke Cast Aluminum |
|
Physical measures and capacities |
|
Dry weight
|
251.0 kg (553.3 pounds) |
|
Weight incl. oil, gas, etc
|
260.0 kg (573.2 pounds) |
|
Seat height
|
653 mm (25.7 inches) If adjustable, lowest setting. |
|
Overall length
|
2179 mm (85.8 inches) |
|
Ground clearance
|
99 mm (3.9 inches) |
|
Wheelbase
|
1519 mm (59.8 inches) |
|
Fuel capacity
|
12.49 litres (3.30 US gallons) |
|
Oil capacity
|
2.60 litres (2.75 US quarts) |
|
Other specifications |
|
Color options
|
Black Denim |
|
Instruments
|
Handlebar-mounted electronic speedometer with odometer, time-of-day clock, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lights |
|
Light
|
High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (optional) |
