| Harley-Davidson's profilation of this bike |
| When you sign your name to the title of a Harley-Davidson® motorcycle, you know you’re getting a bike with style. If that title belongs to a Deuce™, you know you got style taken full-bore. |
|
General information |
|
Motorcycle name
|
Harley-Davidson FXSTDI Softail Deuce |
|
Year
|
2005 |
|
Category
|
Custom / cruiser |
|
Rating
|
3.7 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
1449.0 ccm (88.42 cubic inches) |
|
Engine type
|
V2, four-stroke |
|
Torque
|
101.0 Nm (10.3 kgf-m or 74.5 ft.lbs) @ 3800 RPM |
|
Compression
|
8.8:1 |
|
Bore x stroke
|
95.3 x 101.6 mm (3.8 x 4.0 inches) |
|
Fuel system
|
Injection. Electronic Sequential Port Fuel Injection (ESPFI ) |
|
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
|
Cooling system
|
Air |
|
Gearbox
|
5-speed |
|
Transmission type
|
Belt (final drive) |
|
Clutch
|
Multi-plate clutch with diaphragm spring in oil bath |
|
Exhaust system
|
Over/under shotgun with shorty duals |
|
Chassis, suspension, brakes and wheels |
|
Rake (fork angle)
|
32.0° |
|
Rear tire
|
160/70-17 |
|
Front brakes
|
Double disc |
|
Diameter
|
292 mm (11.5 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
292 mm (11.5 inches) |
|
Physical measures and capacities |
|
Dry weight
|
292.0 kg (643.7 pounds) |
|
Seat height
|
660 mm (26.0 inches) If adjustable, lowest setting. |
|
Overall length
|
2424 mm (95.4 inches) |
|
Ground clearance
|
142 mm (5.6 inches) |
|
Wheelbase
|
1690 mm (66.5 inches) |
|
Fuel capacity
|
18.50 litres (4.89 US gallons) |
|
Other specifications |
|
Color options
|
Vivid black, brilliant silver pearl, sierra red pearl, chopper blue pearl, lava red sunglo, glacier white pearl, two-tone rich sunglo blue and chopper blue pearl, two-tone black cherry pearl and black pearl, two-tone smokey gold pearl and vivid black, two |
| Update specs | Report missing specs or required updates. |
|
Further information |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Parts finder |
Check out our overview of motorcycle webshops at Bikez.info. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 05 Harley-Davidson FXSTDI Softail Deuce discussion group or the general Harley-Davidson discussion group. |
| Related bikes | List related bikes for comparison of specs. |
|
|
|
Rating sample for this Harley-Davidson bike
|
Touring capabilities for the 2005 Harley-Davidson FXSTDI Softail Deuce:
 (63.9 out of 100)
Click here for complete rating. You can also compare bikes.
|
|
