General information |
|
Model
|
Harley-Davidson FXST 1340 Softail |
|
Model year
|
1986 |
|
Category
|
Sport touring |
|
Rating
|
3.5 See the detailed rating of touring capabilities, reliability, accident risk, etc. Compare with any other motorbike. |
|
Engine and transmission |
|
Displacement
|
1337.0 ccm (81.58 cubic inches) |
|
Engine type
|
V2, four-stroke |
|
Power output
|
58.0 HP (42.3 kW)) @ 5000 RPM |
|
Top speed
|
170.0 km/h (105.6 mph) |
|
Compression
|
8.5:1 |
|
Bore x stroke
|
88.8 x 108.0 mm (3.5 x 4.3 inches) |
|
Valves per cylinder
|
2 |
|
Fuel system
|
Carburettor. 40mm Keihin CV |
|
Fuel control
|
Overhead Valves (OHV) |
|
Ignition
|
Single-fire, non-wasted, map-controlled spark ignition |
|
Cooling system
|
Air |
|
Gearbox
|
5-speed |
|
Transmission type
|
Belt (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
38mm Telescopic air assistance |
|
Front wheel travel
|
175 mm (6.9 inches) |
|
Rear suspension
|
Dual shocks preload adjustable |
|
Rear wheel travel
|
91 mm (3.6 inches) |
|
Front tire
|
MH90-21 |
|
Rear tire
|
130/90-16 |
|
Front brakes
|
Single disc. 0 |
|
Diameter
|
292 mm (11.5 inches) |
|
Rear brakes
|
Single disc. Single-piston caliper. |
|
Diameter
|
292 mm (11.5 inches) |
|
Physical measures and capacities |
|
Dry weight
|
280.0 kg (617.3 pounds) |
|
Weight incl. oil, gas, etc
|
290.0 kg (639.3 pounds) |
|
Power/weight ratio
|
0.2071 HP/kg |
|
Seat height
|
680 mm (26.8 inches) If adjustable, lowest setting. |
|
Fuel capacity
|
19.00 litres (5.02 US gallons) |
|
Oil capacity
|
2.80 litres (2.96 US quarts) |
|
Other specifications |
|
Color options
|
Black, blue, red |
|
Starter
|
Electric |
| Update specs | Report missing specs or required updates. |
|
Maintenance and service specs * |
|
Engine oil
|
SAE 20W-50 |
|
Brake fluid
|
DOT 5 Silicone |
|
Battery
|
YTX20H-BS |
|
Spark plugs
|
NGK BPR5ES-11 |
|
Idle speed
|
1000 RPM |
|
Belt teeth
|
132 |
|
Belt width
|
1 1/2 in |
|
Pulley teeth
|
32/70 (front/rear) |
|
Tire pressure front
|
30 PSI (2.1 Bar or 210 kPa) |
|
Tire pressure rear
|
36 PSI (2.5 Bar or 250 kPa) |
|
Fork tube size
|
41 mm (1.6 inches) |
| *) Always verify maintenance and service data with the bike owner's manual. |
|
