| Harley-Davidson's profilation of this bike |
| This is Dyna in its purest form. The Super Glide offers Twin Cam 96 power under a solo seat, cradled in a nimble Dyna chassis. This most affordable example of the Big Twin breed is an inviting canvas for extreme and creative customization.
|
|
General information |
|
Model name
|
Harley-Davidson FXD Dyna Super Glide |
|
Year of manufacture
|
2009 |
|
Type
|
Custom / cruiser |
|
Rating
|
4.0 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
1584.0 ccm (96.66 cubic inches) |
|
Type of engine
|
V2, four-stroke |
|
Torque
|
123.0 Nm (12.5 kgf-m or 90.7 ft.lbs) @ 3125 RPM |
|
Compression
|
9.2:1 |
|
Bore x stroke
|
95.3 x 111.1 mm (3.8 x 4.4 inches) |
|
Fuel system
|
Injection. Electronic Sequential Port Fuel Injection |
|
Cooling system
|
Air |
|
Gearbox
|
6-speed |
|
Transmission type
|
Belt (final drive) |
|
Fuel consumption
|
5.00 litres/100 km (20.0 km/l or 47.04 mpg) |
|
Greenhouse gases
|
116.0 CO2 g/km. (CO2 - Carbon dioxide emission) |
|
Exhaust system
|
Chrome Staggered Shorty Dual exhaust |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Mild steel, tubular frame; rectangular section backbone; stamped, |
|
Rake (fork angle)
|
29.0° |
|
Trail
|
119 mm (4.7 inches) |
|
Front suspension
|
49mm with polished aluminium fork |
|
Front wheel travel
|
127 mm (5.0 inches) |
|
Rear suspension
|
Coil-over shock |
|
Rear wheel travel
|
104 mm (4.1 inches) |
|
Front tire
|
100/90-19 |
|
Rear tire
|
160/70-B17 |
|
Front brakes
|
Single disc. 4-piston |
|
Diameter
|
300 mm (11.8 inches) |
|
Rear brakes
|
Single disc. 2-piston |
|
Diameter
|
292 mm (11.5 inches) |
|
Physical measures and capacities |
|
Dry weight
|
286.0 kg (630.5 pounds) |
|
Seat height
|
675 mm (26.6 inches) If adjustable, lowest setting. |
|
Overall height
|
1188 mm (46.8 inches) |
|
Overall length
|
2357 mm (92.8 inches) |
|
Ground clearance
|
135 mm (5.3 inches) |
|
Wheelbase
|
1630 mm (64.2 inches) |
|
Fuel capacity
|
18.16 litres (4.80 US gallons) |
|
Other specifications |
|
Starter
|
Electric |
|
Comments
|
Silver powder-coated engine and polished rocker boxes. |
