2009 Harley-Davidson FLHTC Electra Glide Classic. Picture credits - Harley-Davidson.
Submit more pictures.
|
|
| Harley-Davidson's profilation of this bike |
| Go beyond the touring basics aboard the Electra Glide Classic, which comes equipped with an adjustable Tour-Pak, 40-watt Advanced Audio System by Harman/Kardon, and full instrumentation, plus additional fender and saddlebag trim, for beyond-the-basics touring comfort and versatility.
|
| General information |
|---|
| Model: | Harley-Davidson FLHTC Electra Glide Classic |
| Year: | 2009 |
| Category: | Touring |
| Rating: | 3.9 See the detailed rating of touring capabilities, reliability, accident risk, etc. Compare with any other motorbike. |
| Engine and transmission |
|---|
| Displacement: | 1584.0 ccm (96.66 cubic inches) |
| Engine type: | V2, four-stroke |
| Torque: | 125.0 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 3500 RPM |
| Compression: | 9.2:1 |
| Bore x stroke: | 95.3 x 111.1 mm (3.8 x 4.4 inches) |
| Fuel system: | Injection |
| Cooling system: | Air |
| Gearbox: | 6-speed |
Transmission type,
final drive: | Belt |
| Clutch: | 9-plate, wet |
| Fuel consumption: | 5.00 litres/100 km (20.0 km/l or 47.04 mpg) |
| Greenhouse gases: | 116.0 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Exhaust system: | New Two-into-One-into-Two chrome exhaust with |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type: | New mild steel, single spar rigid backbone with |
| Rake (fork angle): | 26.0° |
| Trail: | 170 mm (6.7 inches) |
| Front suspension: | 41.3mm telescopic, cartridge-style damping |
| Front wheel travel: | 117 mm (4.6 inches) |
| Rear wheel travel: | 76 mm (3.0 inches) |
| Front tyre: | 130/80-B17 |
| Rear tyre: | 180/65-B16 |
| Front brakes: | Double disc |
| Diameter: | 300 mm (11.8 inches) |
| Rear brakes: | Single disc |
| Diameter: | 300 mm (11.8 inches) |
| Physical measures and capacities |
|---|
| Dry weight: | 375.0 kg (826.7 pounds) |
| Seat height: | 715 mm (28.1 inches) If adjustable, lowest setting. |
| Overall height: | 1549 mm (61.0 inches) |
| Overall length: | 2469 mm (97.2 inches) |
| Ground clearance: | 129 mm (5.1 inches) |
| Wheelbase: | 1613 mm (63.5 inches) |
| Fuel capacity: | 22.70 litres (6.00 gallons) |
| Other specifications |
|---|
| Starter: | Electric |
| Comments: | Sidecar possible. ABS available. |
| Further information |
|---|
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Finance options | Compare US motorcycle loan quotes from the nation's top providers. |
| Parts finder |
Chaparral provides online schematics & OEM parts for the US. Revzilla offers up to 50% off motorcycle accessories. Ships to most countries.
Also check out our overview of motorcycle webshops at Bikez.info. |
| Ask questions | Join the 09 Harley-Davidson FLHTC Electra Glide Classic discussion group or the general Harley-Davidson discussion group. |
| Related bikes | List related bikes for comparison of specs. |
|
|
|
Rating sample for this Harley-Davidson bike
|
Touring capabilities for the 2009 Harley-Davidson FLHTC Electra Glide Classic:
 (99.6 out of 100)
Click here for complete rating. You can also compare bikes.
|
|
