1971 Harley-Davidson FL 1200 Electra Glide. Picture submitted by anonymous user..
Submit more pictures.
|
|
|
General information |
|
Model name
|
Harley-Davidson FL 1200 Electra Glide |
|
Year model
|
1971 |
|
Type
|
Classic |
|
Rating
|
3.3 See the detailed rating of design and look, engine performance, reliability, fun-factor, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
1206.0 ccm (73.59 cubic inches) |
|
Type of engine
|
V2, four-stroke |
|
Effect
|
58.0 HP (42.3 kW)) @ 5150 RPM |
|
Top speed
|
164.0 km/h (101.9 mph) |
|
Compression
|
8.0:1 |
|
Bore x stroke
|
87.3 x 100.8 mm (3.4 x 4.0 inches) |
|
Valves per cylinder
|
2 |
|
Fuel control
|
Overhead Valves (OHV) |
|
Cooling system
|
Air |
|
Gearbox
|
4-speed |
|
Transmission type
|
Chain (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Front tire
|
5.10-16 |
|
Rear tire
|
5.10-16 |
|
Front brakes
|
Expanding brake |
|
Rear brakes
|
Expanding brake |
|
Physical measures and capacities |
|
Weight incl. oil, gas, etc
|
340.0 kg (749.6 pounds) |
|
Fuel capacity
|
19.00 litres (5.02 US gallons) |
|
Other specifications |
