| General information |
|---|
| Model: | Harley-Davidson Electra Glide Ultra Limited |
| Year: | 2013 |
| Category: | Touring |
| Price as new: | US$ 24199. Euro 27495. UK £ 21195. MSRP depends on country, taxes, accessories, etc. |
| Rating: | 3.5 See the detailed rating of touring capabilities, reliability, accident risk, etc. Compare with any other motorbike. |
| Engine and transmission |
|---|
| Displacement: | 1688.0 ccm (103.00 cubic inches) |
| Engine type: | V2, four-stroke |
| Engine details: | Air-cooled Twin Cam 103â„¢ with Integrated Oil-Cooler |
| Torque: | 135.6 Nm (13.8 kgf-m or 100.0 ft.lbs) @ 3250 RPM |
| Compression: | 9.6:1 |
| Bore x stroke: | 98.4 x 111.3 mm (3.9 x 4.4 inches) |
| Fuel system: | Injection. Electronic Sequential Port Fuel Injection |
| Lubrication system: | Dry sump |
| Cooling system: | Oil & air |
| Gearbox: | 6-speed |
Transmission type,
final drive: | Belt |
| Clutch: | Multi-plate with diaphragm spring in oil bath |
| Driveline: | Chain, 34/46 ratio primary drive |
| Fuel consumption: | 5.60 litres/100 km (17.9 km/l or 42.00 mpg) |
| Greenhouse gases: | 129.9 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Exhaust system: | Chrome, 2-1-2 dual exhaust with tapered mufflers |
| Chassis, suspension, brakes and wheels |
|---|
| Rake (fork angle): | 26.0° |
| Trail: | 170 mm (6.7 inches) |
| Front tyre: | 130/80-17 |
| Rear tyre: | 180/65-16 |
| Front brakes: | Double disc. 4-piston |
| Rear brakes: | Single disc. 2-piston |
| Wheels: | Black and Chrome, 28-spoke Cast Aluminum |
| Physical measures and capacities |
|---|
| Dry weight: | 400.1 kg (882.0 pounds) |
| Weight incl. oil, gas, etc: | 413.2 kg (911.0 pounds) |
| Seat height: | 693 mm (27.3 inches) If adjustable, lowest setting. |
| Overall length: | 2504 mm (98.6 inches) |
| Ground clearance: | 130 mm (5.1 inches) |
| Wheelbase: | 1613 mm (63.5 inches) |
| Fuel capacity: | 22.71 litres (6.00 gallons) |
| Oil capacity: | 3.80 litres (0.25 quarts) |
| Other specifications |
|---|
| Color options: | Anniversary Vintage Bronze/Anniversary Vintage Black, Chrome Yellow Pearl/Vivid Black with HD Orange Pinstripes, Midnight Pearl/Brilliant Silver Pearl with Dark Blue Pinstripes, Ember Red Sunglo/Merlot with Medium Red Pinstripes, Big Blue Pearl/Vivid Blac |
| Starter: | Electric |
| Instruments: | Fairing-mounted electronic speedometer with odometer; time-of-day clock on CD player/stereo; dual trip meter; low fuel indicator light and mileage countdown feature; low oil pressure indicator light; engine diagnostics readout; LED indicator lights; 6-speed indicator light; cruise control indicator light Tachometer with fuel, voltage, oil pressure and ambient air temperature gauges |
| Light: | High beam, running lights, front fender running lights, directional light bar, low oil pressure, engine diagnostics, cruise control, speakers, accessory, security system, 6-speed, low fuel warning, ABS |
| Carrying capacity: | Saddle bags, top box |
| Comments: | Windshield. |
