| General information |
|---|
| Model | Harley-Davidson 1340 Springer Softail |
| Year | 1989 |
| Category | Classic |
| Rating | 3.6 See the detailed rating of design and look, engine performance, reliability, fun-factor, etc. Compare with any other bike. |
| Engine and transmission |
|---|
| Displacement | 1337.0 ccm (81.58 cubic inches) |
| Engine type | V2, four-stroke |
| Power | 58.0 HP (42.3 kW)) @ 5000 RPM |
| Torque | 116.6 Nm (11.9 kgf-m or 86.0 ft.lbs) @ 3500 RPM |
| Top speed | 165.0 km/h (102.5 mph) |
| Compression | 8.5:1 |
| Bore x stroke | 88.8 x 108.0 mm (3.5 x 4.3 inches) |
| Valves per cylinder | 2 |
| Fuel system | Carburettor |
| Fuel control | Overhead Valves (OHV) |
| Ignition | Single-fire, non-wasted, map-controlled spark ignition |
| Lubrication system | Dry sump, internally mounted, crank driven gerotor. |
| Cooling system | Air |
| Gearbox | 5-speed |
| Transmission type | Belt (final drive) |
| Clutch | Wet 9-plate |
| Exhaust system | Staggered shorty duals |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type | Steel tubular, rectangle-section backbone. |
| Rake (fork angle) | 27.5° |
| Trail | 134 mm (5.3 inches) |
| Front suspension | Chrome, leading-link |
| Rear suspension | Hidden, horizontal-mounted, coil-over |
| Front tire | MH90-21 |
| Rear tire | 150/80-B16 |
| Front brakes | Single disc. Two-piston calipers. |
| Diameter | 292 mm (11.5 inches) |
| Rear brakes | Single disc. Four-piston calipers. |
| Diameter | 292 mm (11.5 inches) |
| Physical measures and capacities |
|---|
| Dry weight | 298.0 kg (657.0 pounds) |
| Weight incl. oil, gas, etc | 299.0 kg (659.2 pounds) |
| Power/weight ratio | 0.1946 HP/kg |
| Seat height | 655 mm (25.8 inches) If adjustable, lowest setting. |
| Overall length | 2375 mm (93.5 inches) |
| Ground clearance | 130 mm (5.1 inches) |
| Wheelbase | 1661 mm (65.4 inches) |
| Fuel capacity | 16.00 litres (4.23 US gallons) |
| Other specifications |
|---|
| Starter | Electric |
